Aceco FC-3002 and ICOM IC-R20 wiretaps detecting and locating set

796,91 $

Availability: On order

Delivery from Check the shipping costs

Place an order within And we will send your order today 01h 31m 56s

Do you need advice? Write to us

You dont know if you chose right? Leave your phone number and we will call you back

Description

Product unavailable!
Buy similar product: Protect 1207i six-channel wiretap detector.

Aceco FC-3002 and ICOM IC-R20 wiretaps detecting and locating set

The presented set are perfectly cooperating tools for detecting and listening of various kinds of transmissions. It also allows to locate the transmitter and neutralize it.

FC-3002 frequency meter captures the signal and the connected IC-R20 wideband scanner adjusts itself automatically to the given frequency and allows to check if the transmission comes from a wiretap, wireless camera or insignificant source.

Locating the danger is possible thanks to a built-in signal power meter, which generates the results on a clear LCD display, or informs with a sound about the signal's strength.

The set, which includes the meter and the scanner, is a perfect combination of precise equipment which allow to detect and protect oneself against data stealing and interfering our privacy.

Aceco FC-3002

Frequency range

1 MHz - 3 GHz
Work time

up to 6 h
Power supply

Ni-Cd battery
Display

LCD

Scanner ICOM IC-R20

Frequency range

0.150 to 1304.999 MHz

1305.000 to 3304.999 MHz
Current consumption

150 mA

100 mA

35 mA
Power supply

Lithium-ion battery
USB port

3.5 mm jack

Specification

Specification of wiretaps locating and detecting set
FC-3002 frequency meter
Frequency measurement range and signal period	1 MHz – 3 GHz
Detector	histogram – 16 sections to RF signal representation ultra-sensitive synchronous
Counter	speed: 300 MHz resolution: 0.1 Hz
Display screen	10-digit LCD backlight
Accumulator	Ni-CD
Accumulator work time	6 hours
Amplifier	1 MOhm 50 Ohm
Impedance	1 MOhm, 30pF 50 Ohm, VSWR < 2:1
Sensitivity	< 10 mV@ 10 Hz ÷ 10 MHz < 20 mV @10 MHz ÷ 50 MHz < 0.8 mV @ 100 MHz < 6 mV @ 300 MHz < 7 mV @ 1 GHz < 100 mV @ 2.4 GHz
Maximum input signal	100 Vrms 15 dBm
Scanner ICOM IC-R20
Frequency ranges	0.150 to 1304.999 MHz 1305.000 to 3304.999 MHz
Dualwatch VFO A	0.150 to 469.999 MHz (AM, FM, WFM, LSB, USB, CW)
Dualwatch VFO B	118 to 174.999 330 to 1304.999 (AM, FM, WFM)
Broadband reception	AM , FM, WFM , SSB (LSB and USB ), CW
Programmable tuning step	0.01, 0.1, 5, 6.25, 8.33, 9, 10, 12.5, 15, 20, 25, 30, 50, 100 KHz
Receiver system	triple conversion superheterodyne frequency + down converter
Intermediate frequencies	sensitivity, band 266.7 MHz, 429.1 MHz 19.65 MHz 450 kHz
Memory	1250 channels 1000 standard 200 automatic 50 band edges
Antenna Impedance	50 Ohm BNC
Current consumption ( 3.7 V DC)	rated audio mode: around 150 mA (backlight off) standby mode: around 100 mA (backlight off) energy save mode: 35 mA (duty 1:4)
Audio output power (at 3.7 V DC)	around 0.1 W 10 % distortion 8 Ohm load
External speaker connector	3 - conductor 3.5 (mean) mm / 8Ohm
Operating temperature range	-10° C - +60° C
Dimensions (with BP -206)	60 × 142 × 34.8 mm
Weight	320 g (with antenna and BP -206)

Sensitivity

Modulation	Band	Sensitivity
FM (12dB SINAD)	1.620 - 4.999 5.000 - 221.999 330.000 - 832.999 833.000 - 1304.999 1330.000 - 2304.999 2330.000 - 2999.999	0.56 0.40 0.56 0.71 5.60 18.0
WFM (12dB SINAD)	76.000 - 108.000 175.000 - 221.999 470.000 - 769.999	1.80 1.80 2.50
AM (10dB S/N)	0.495 - 4.999 5.000 - 29.999 118.000 - 135.999	2.20 2.20 1.40
SSB/CW (10dB S/N)	0.495 - 4.999 5.000 - 29.999 50.000 - 53.999 118.000 - 146.999 330.000 - 469.999	0.40 0.25 0.25 0.25 0.32
