The compact AGM Rattler TC35-384 thermal imaging cap provides excellent visibility at distances up to 1,750 m. The sensitive thermal sensor with a resolution of 384x288 and a refresh rate of 50 Hz gives a detailed image even in the complete absence of light.
19 mm
35 mm
50 mm
3 years
2× CR123 battery
2×,4×,8×
Another great piece of equipment from AGM is the Rattler TC35-384 thermal imager for the hunter, with a range of up to 1750m. It will be great for operations in such conditions as nighttime in dense forest, fog, snow or smoky rooms - anywhere where daytime optics will fail. The image is displayed on a 748×561 OLED screen with excellent color reproduction and detail. This is complemented by a built-in stadiameter rangefinder, 8x digital zoom, smooth 50Hz refresh rate and a rugged, waterproof housing. The Rattler TC35-384 thermal imaging overlay from the American company AGM Global Vision is recommended for hunters, private investigatorss and uniformed services for whom effective observation from considerable distances is of particular importance.
Thanks to the Ulis microbolometer sensor with a resolution of 640×512, the observation range reaches up to 2500 m in open terrain and under favorable weather conditions. The thermal imaging technology does not require external light for operation. The TC35-384 model equipped with a 384×288 sensor has a range of up to 1,750m.
The built-in stadiameter rangefinder allows you to determine the distance to a target by marking the top and bottom of the target. An invaluable feature for hunters.
Thanks to the 50 Hz refresh rate, the displayed image is smooth and without streaking or stuttering.
The image is displayed on an OLED screen, which guarantees good reproduction of details and colors.
The AGM Rattler is equipped with a bright lens with F/1.0 light. This, combined with up to 8x digital zoom, results in excellent visibility and the ability to make effective observations over a considerable distance.
An optional Wi-Fi module for remote operation and a video recorder can be hooked up to the device. Collected files are stored on the 16 GB internal memory.
The hunting thermal imager has dimensions of 153 × 62 × 59 mm and a weight of only about 450 g. As a result, the device will not affect the accuracy of the weapon and the comfort of the shooter.
The AGM Rattler hunting thermal imager has a housing made of durable aluminum, which provides high resistance to mechanical damage, dust moisture and extreme temperatures (ranging from -20°C to +55°C).
Specification AGM RATTLER TC19-256 / TC35-384 / TC50-640 | |||
---|---|---|---|
TC19-256 | TC35-384 | TC50-640 | |
Sensor type | uncooled focal plane array | uncooled | uncooled focal plane array |
Sensor resolution | 256 × 192 | 384 × 288 | 640 × 512 |
Refresh rate | Sensor 25 Hz / OLED 50 Hz | Sensor 50 Hz / OLED 50 Hz | Sensor 50 Hz / OLED 50 Hz |
Spectral spectrum | 8 μm to 14 μm | - | 8 μm to 14 μm |
Pixel size | 12 μm | 17 μm | 12 μm |
Detection range | 950 m | 1750 m | 2500 m |
Lens | 19 mm, F1.0 | 35 mm, F1.0 | 50 mm, F1.0 |
Field of view (H × X) | 9,2° × 6,9° | 10,0° × 8,0° | 8,8° × 7,0° |
Digital magnification | 1×, 2×, 4×, 8× | 2×, 4×, 8× | 1×, 2×, 4×, 8× |
Display | 1024x768, 0.39 inch, OLED | - | 1024x768, 0.39 inch, OLED |
FFC (Flat Field Correction) | Auto, Manual, External Correction | - | Auto, Manual, External Correction |
Palettes | Black Hot, White Hot, Red Hot, Fusion | - | Black Hot, White Hot, Red Hot, Fusion |
Scenes | Jungle, Recognition | - | Jungle, Recognition |
Spot tracking of highest temperature | Yes | - | Yes |
Rest mode | Yes | ||
Built-in memory | 16 GB | 16 GB | 16 GB |
Interface | USB | ||
Power supply | 2× CR123A, RCR123A | 2× CR123A, RCR123A | 2× CR123A, RCR123A |
Operating time | Up to 4.5 h | ||
Protection classification | IP67 | ||
Operating temperature | from -20 °C to 55 °C | ||
Dimensions | 153 mm × 62 mm × 59 mm | 153,2 mm × 62,5 mm × 59,2 mm | 153 mm × 78 mm × 66 mm |
Weight | 410 g | 420 g | 490 g |
Inbox |
---|
Specification AGM RATTLER TC19-256 / TC35-384 / TC50-640 | |||
---|---|---|---|
TC19-256 | TC35-384 | TC50-640 | |
Sensor type | uncooled focal plane array | uncooled | uncooled focal plane array |
Sensor resolution | 256 × 192 | 384 × 288 | 640 × 512 |
Refresh rate | Sensor 25 Hz / OLED 50 Hz | Sensor 50 Hz / OLED 50 Hz | Sensor 50 Hz / OLED 50 Hz |
Spectral spectrum | 8 μm to 14 μm | - | 8 μm to 14 μm |
Pixel size | 12 μm | 17 μm | 12 μm |
Detection range | 950 m | 1750 m | 2500 m |
Lens | 19 mm, F1.0 | 35 mm, F1.0 | 50 mm, F1.0 |
Field of view (H × X) | 9,2° × 6,9° | 10,0° × 8,0° | 8,8° × 7,0° |
Digital magnification | 1×, 2×, 4×, 8× | 2×, 4×, 8× | 1×, 2×, 4×, 8× |
Display | 1024x768, 0.39 inch, OLED | - | 1024x768, 0.39 inch, OLED |
FFC (Flat Field Correction) | Auto, Manual, External Correction | - | Auto, Manual, External Correction |
Palettes | Black Hot, White Hot, Red Hot, Fusion | - | Black Hot, White Hot, Red Hot, Fusion |
Scenes | Jungle, Recognition | - | Jungle, Recognition |
Spot tracking of highest temperature | Yes | - | Yes |
Rest mode | Yes | ||
Built-in memory | 16 GB | 16 GB | 16 GB |
Interface | USB | ||
Power supply | 2× CR123A, RCR123A | 2× CR123A, RCR123A | 2× CR123A, RCR123A |
Operating time | Up to 4.5 h | ||
Protection classification | IP67 | ||
Operating temperature | from -20 °C to 55 °C | ||
Dimensions | 153 mm × 62 mm × 59 mm | 153,2 mm × 62,5 mm × 59,2 mm | 153 mm × 78 mm × 66 mm |
Weight | 410 g | 420 g | 490 g |
