GPS-305 - Bike GPS tracker in a handlebars

More info

Bike GPS tracker in a handlebars - GPS-305

The Bike GPS tracker GPS-305 is installed in a bicycle's head tube (the most popular standard: A-Head 1 1/8") just under the top cap. The GPS-305 tracker is not a security measure for bicycles, but an alternative tool, useful for locating the bicycle in case it is stolen.

GPS tracking

accuracy up to 5 m
Location

on demand

scheduled
GPS antenna

built-in
Operation time

some 30 days

The Bike GPS tracker GPS-305 head tube locator was designed to be installed in the least expected of places. A bicycle's head tube is very important element that cannot be remove without a set of appropriate tools. This gives the users of GPS-305 a better chance of finding stolen bicycles than users of other similar devices, which can be simply removed and thrown away.

GPS-305 bike tracker in a handlebars is a perfect solution for cases when traditional locks do not prevent a bicycle from being stolen. It is completely invisible, placed in a head tube, easy to handle and install. It is the most frequently chosen GPS transmitter and the most frequenty utilised alternative supplement for regular bicycle security.

Key features of GPS-305 bike GPS tracker

Power supply

The GPS bike tracker is powered by a 700mAh Li-Poly battery. Operation time depends on the selected reporting mode, from 5 hours in case of multiple reports per day, to 30 days in standby mode.
Text message commands

The device can be operated by means of text message commands sent to the number of the SIM card installed in the tracker. It is possible to configure up to 5 authorized numbers.
On-demand location

In case of theft it is possible to locate the bicycle quickly – in response to a text message command, a message is being sent, containing a link to a map with the device's position marked.
GeoFence - safety zones

Allows to set “safety zones”, within which the tracked person can move freely. Upon crossing its border, the administrator is being sent a notification.

Note!
The SIM must be active, unprotected by PIN codes, and have sufficient funds assigned for sending text messages and data transfer.

Manufacturer

Spy Shop

Spy Shop is a company created for the needs of providing high class spy devices constructed for monitoring and protecting the property, protecting confidential information, anti-spy activities, supervision and many others. The target group of Spy Shop are as well individual...

Specification

Specification of the Bike GPS tracker in a handlebars GPS-305
¹ full sky visibility ² removable ³ no batteries
GPS band	L1, 1575.42MHz
GPS antena	integrated
Sensitivity of the Bike GPS tracker	typical: -159 dBm
Accuracy	location: up to 5 m supported by SBAS: ~5 - 10 m speed: 0,1m/s
Launch time of the Bike GPS tracker ¹	Cold Start: 60s (average) Warm Start: < 30s Hot Start: < 1s
GPS	chipset GSTARGS-92U7 56 channels
Quad GSM module	850/900/1800/1900MHz
Power supply of the Bike GPS tracker in a handlebars	accumulator Li-Poly 700mAh ²
Charging voltage	3,7V DC
Voltage of external accumulator	3,5 – 4,5V
Operation time	in sleep mode: up to 30 days 20 reports a day: up to 5 h
Charging time	up to 5 h
Operation temperature	-20°C - 70°C
Admissible humidity	5 - 95%
Size	φ23,5 × 110mm
Weight of the Bike GPS tracker ³	50 g

Inbox

Locator for accumulator Li-Poly 700mAh, 3,7V
Network charger
Mounting screw M6
Inductive key of the Bike GPS tracker
User manual
