PDS-200 SE is a professional cell phone detection system in a controlled building and it consists of the set of detectors (max. 64) connected to the central unit - a PC with a specialist WCMS software installed. Configuration can be adjusted to the user’s requirements, depending on the size and floorplan of the monitored building.
You can download the floorplan of the building into the detector’s system and map the position of each detector on it to facilitate locating of places where the alarm is activated and quickly take necessary steps. This professional cell phone detection system will perfectly do e.g. in prisons and other places with areas where the use of mobile phones is not allowed.
You can connect up to 64 detectors to the system, connecting them to the PC as a central unit with the specialist WCMS software installed.
It has been created to process and analyze radio signals captured by the PDS-2000 SE detectors located in the monitored areas of the building.
The cell phone detection system can work in fully automatic mode with a minimum operation requirements - when configured accordingly, it will be able to provide you with all the information you need.
The PDS-2000 SE cell phone detection system will notify you on detection of unauthorized GSM connection. In result, audible and visual alarm goes off in the system central unit. All alarms are recorded for further verification and analysis of their appearance.
When GSP transmission has been detected, the connected jammer can be automatically activated.
The executive element of the system is the PDS-2000 detector which enables detecting of the following transmissions:
Additionally, the cell phone detection system is able to control external devices and can activate the compatible jammer or alarm siren connected to it.
Senstivity of each PDS-2000 SE detector can be adjusted and the area of signal detection can be extended or narrowed.
Specification of the cell phone detection system PDS-2000 SE | |
---|---|
WCMS software | |
Compatibility | with PC computers |
Supported operation systems | Windows XP |
Quick cell phone location | possibility of uploading the object map |
Alarm logs | logs for further analysis |
Cell phone detection system PDS-2000 | |
---|---|
Supported frequencies |
|
Types of detected signals |
|
Up-link detection | from a cell phone to the base |
Sensitivity adjustment | 55dBm to -30dBm |
Detection range | 15 - 30 m |
Connection interface | RS-485 |
12V output | controls external devices (jammer, alarm) |
Power supply voltage | 12V |
Electricity consumption | 500mA |
Input/Output of the alarm power supply | 220V 5A |
Operation temperature | -10°C - 70°C |
Admissible humidity | 5% - 80% |
Dimensions | 22,5 × 16,5 × 4,5 cm |
Weight | 2 kg |
