Dauha DVR DHI-NVR4104-W for 4 IP 5 Mpix cameras with instant access and android compatibility
Dauha DVR DHI-NVR4104-W for 4 IP 5 Mpix cameras with instant access and android compatibility

  • Customer rating:
    Average: 0
    Nobody has posted a review yet
    Rate / write a comment
  • Delivery from £ 3.50
    Delivery servicePrepaymentCash on Delivery
    UPS delivery service £ 3.50 £ 8.50
    See shipping costs
  • Ask Expert: (44) 20 3290 1199
    Sales representative and Consultant
    John Paine

    Helpdesk

    (44) 20 3290 1199

Dauha DVR DHI-NVR4104-W for 4 IP 5 Mpix cameras with instant access and android compatibility

  • Possible to connect 4 IP cameras
  • Maximum definition 5 Mpx
  • Pocket for SATA 4 TB disc
  • Video slots: HDMI/VGA
  • Compression: H.264/MJPEG

Availability: Available


£139.00tax inc.

Add to cart

  • Print

More info

Dauha DVR DHI-NVR4104-W for 4 IP 5 Mpix cameras with instant access and android compatibility

Four-channel Dauha DVR DHI-NVR4104-W for Ip cameras enables monitoring of the surrounding with the possibility of real-time view on mobile devices by up to 128 users simultaneously.

  • Camera support

    IP Cameras

    max. 4

  • Quick access

    Remote access

    Android, iOS/ Windows

  • Recording after motion detection

    Operating modes

    motion detection

    schedule

  • Image quality

    3D Positioning

    yes

The Dauha DVR DHI-NVR4104-W Dahua cooperates with up to 4 IP cameras.Built-in dual-core processor ensures efficient and quick operation. IP connection enables remote control of the footage and live view. The Dauha DVR supports cameras with the maximum resolution of 5 Mpix and enables saving 1080P video files and 2560×1920 photos.

Monitoring can be adjusted to individual requirements of the use and to the surrounding conditions. The operator can choose between motion detection, schedule recording or 24/h operation mode. Another useful feature is further search of the footage by date and time of the event or by motion detection. The Pentaplex function allows to preview the collected footage, record evens and give live view at the same time.

The IP Dauha DVR has a pocket for a disc with the maximum capacity of 4 TB to store the footage. To preview, delete video files or photos or to change the settings of the recorder you just need to connect with the device via a free Smart PSS application from any place in the world.

Ip WiFi Dahua DVR DHI-NVR4104-W has been designed for CCTV monitoring of playing fields, offices, stores, warehouses and schools.

IP recorder

Key features of IP Dahua DVR DHI-NVR4104-W

  • pocket for SATA 4 TB disc
  • P2P communication
  • operation of 4 IP cameras
  • remote control of the footage and settings
  • compliant with ONVIF protocol
  • 4 operating modes
  • Bit Rate 80 Mbps
  • H.264 compression

Example configuration diagram of IP Dahua CCTV

IP recorder connections

Manufacturer

Dahua

Dahua - surveillance solutions, industrial monioring systems of the highest quality.

Specification

Specification of the Dauha DVR DHI-NVR4104-W for 4 IP 5 Mpix cameras
Ogólne
Processordual-core
Operation systemLinux
Compatible systems
  • Windows Vista/ Windows 7/ Windows 8
  • Android, iOS
USB2× USB 2.0
Operation systemLinux
Supported hard drives1× SATA, maks. 4 TB
Camera input4 channels
Inputs
  • 1× HDMI
  • 1× VGA
Audio
Input / output1 channel, RCA
2-direction audioyes
Alarmno
Image management
Resolution of the Dauha DVR
  • 4 @ 2560 × 1920 px
  • 4 @ 2048 × 1536 px
  • 4 @ 1920 × 1080 px
  • 4 @ 1280 × 720 px
  • 4 @ 704 × 576 px
  • 4 @ 704 × 576 px
Privacy hidingno
Video compressionH.264
Audio compressionG711A
Bits transmission speed48~8192 kbps
Recording speed
  • 2560×1920 (32 fps)
  • 1920×1080, 1280×720, 704×576, 2048×1536 (100 fps)
Interval
  • 1-120 min (default 60 min)
  • before recording 1-30 s
  • after recording 10-300 s
Max bitrate IP80 Mbps
Recording mode
  • manual
  • schedule
  • motion detection
Searching speed
  • browsing the content
  • with channels
  • with date and time
  • after motion detection
Network
Ethernet1 port RJ-45 (10/100Mbps)
NetworkHTTP, IPv4/IPv6, TCP/IP, UPNP, RTSP, UDP, SMTP, NTP, DHCP, DNS, PPPOE, DDNS, FTP, IP Filter, SNMP, P2P
Max. users numberup to 128
Others
Operation temperature-10°C~+55°C
Power10 W
Power supplyDc 12 V
Dimensions of the Dauha DVR205×205×45 mm
Weight0,5 kg

Inbox

  • Dauha DVR DHI-NVR4104-W for 4 IP 5 Mpix cameras with instant access and android compatibility
  • Software
