Order modernised version: Talan 3.0 System for telephone line analysis and detection of analog and digital wiretaps in VoIP telephones system.
Telephone and Line Analyzer - DPA-7000 TALAN
The DPA-7000 to is an instrument for analysis, detection of anomalies and location of possible sources of threat to telephone systems.
The TALAN DPA-7000 is a professional system designed for inspecting telephone lines in order to detect and locate possible surveillance device, as well as to assess the security level. It is compatible with analogue, digital and VoIP phones alike.
Features of the Telephone and Line Analyzer
-
Automated tests suite
Multiple automatic tests conducted by DPA-7000 TALAN system allow to inspect phone lines for unauthorized surveillance. Due to the automatic switching matrix, all possible combinations are tested – e.g. an 8-wire cable means 28 pairs, every one of which is tested. The results are stored for possible further analysis.
-
Digital demodulation
Telephone and line analyzer allows to determine whether an inspected line is used to transfer audio signals. DPA-7000 TALAN is capable of decoding approximately 80% of digital phone systems used worldwide.
-
Frequency domain reflectometer (FDR)
Possible presence of a security threat is determined by detecting phone line's impedance anomalies. It allows to conduct comparative analysis for multiple pairs of wires and to compare results with previously collected information.
-
Non-linear junction detection (NLJD)
DPA-7000 TALAN detects all electronic devices connected to a specific inspected line. It allows for easy determination whether any unidentified – and potentially dangerous – devices are attached to the line.
-
Digital multimeter
Measures the basic electrical parameters of telephone lines, such as voltage, current, or resistance. The switching matrix allows to analyse all possible wire combinations, while clear display of results makes it possible to identify anomalies.
-
Audio amplifier with built-in oscilloscope
Voice band audio signal amplifier (20Hz – 20kHz, 80dB total gain). A DC bias generator allows to power attached electronics.
-
RF signal analysis and detection
Detailed spectrum analysis (frequency up to 85MHz) and time domain display (shows AM and FM modulation). Due to a broadband RF probe, it is possible to analyse RF energy up to 8GHz and depict its level over time, allowing to locate radio transmitters.
-
VoIP (voice-over internet protocol) phone analysis
Ability to test VoIP phones – so-called Internet utilising IP protocol. Telephone and line analyzer collects address data, MAC/IP addresses, header types and statistical data, providind the possibility to filter them according to user-defined settings. It is possible to connect the device to non-POE (Power Over Ethernet) 10/1000Mbps lines using an adapter. Collected information is stored on USB memory or a Compact Flash card.
-
Specialist software of the telephone and line analyzer
Included software allows for transparent display of collected data, as well as to analyse and export it, and to generate reports. DPA-7000 TALAN also provides the possibility to compare multiple lines simultaneously and identify potential threats.
Specification
Specification of DPA 7000 TALAN - Telephone and Line Analyzer | |
---|---|
Control unit | |
Processor of the Line Analyzer | 32bit RISC, 520MHz |
Internal memory | 64MB SDRAM (OS), 64MB Flash |
External memory | compact Flash up to 2GB |
Digital I/O ports | |
---|---|
USB (type A) | external keyboard, mouse, or an USB drive |
Ethernet | 10/100 Ethernet controller |
Host USB (type B) | compact Flash up to 2GB |
Analog I/O | |
---|---|
Headphone output | 3.5mm mono connector |
Microphone input | 3.5mm mono input |
User interface | |
---|---|
Hard keys | 6 soft menu keys, 5 button quadrant navigation & other dedicated keys |
Encoder | high-resolution optical encoder |
Display of DPA-7000 TALAN | touch screen with stylus |
Hard keys | 6 soft menu keys, 5 button quadrant navigation & other dedicated keys |
Test inputs | |
---|---|
Dual MOD8 | supports 2, 4, 6, & 8 wire modular phone jacks |
Banana type | standard sleeved sockets: ring, tip, and earth |
SMB RF input of Telephone and Line Analyzer | RF/antenna connection to 8 ghz broadband detector |
Expansion port of the telephone and line analyzer | supports communication and measurement for use with future accessories |
RF system | |
---|---|
Spectrum analyzer | |
Receiver | super-heterodyne with dual conversion |
Frequency range | 30kHz to 85MHz |
Sweep time | 2 seconds |
Step size | 1kHz |
Bandwidth of the telephone and line analyzer | 18kHz |
Sensitivity | -100dBm |
Broadband detector | |
---|---|
RF SMB input | to 8GHz |
Line level test | 100kHz to 600MHz |
Sensitivity | -65dBm |
Digital multimeter | |
---|---|
Range of DPA-7000 TALAN | response auto-ranging, 500msec sample rate |
AC/DC volts | 0 to 250V max. |
Resistance | 0 to 40 MegOhm |
Capacitance | 4nF to 4.2ľF |
Bias generator | |
---|---|
High voltage DAC | optically isolated, direct digital control |
Modulation | fixed voltage, or variable rate sinewave (10Hz - 300Hz) |
Output voltage | ± 80V |
Audio | |
---|---|
Audio bandwidth | 20Hz - 20KHz |
Gain | up to 80dB total system gain (voice band) |
AGC | digitally controlled automatic gain |
Filter | analog voice band filter (300Hz to 3kHz) |
Mechanical | |
---|---|
External input | 9 - 15VDC @ 3A |
Universal power supply | 100-240VAC, 50-60Hz |
Removable battery | rechargeable Li-Ion, 4-6 hours of run time |
Operating temperature | 0°C to +50°C |
Weight with battery | 2.7 kg |
Set weight | 7.1 kg (Including TALAN and accessories) |
Case dimension | 13.7cm × 37.8cm × 49.5cm |
Dimensions | 25.4cm × 32.8cm × 6.9cm |
