DS1 Docking station for wireless cameras charging
DS1 Docking station for wireless cameras charging
  • Customer rating:
    Average: 0
    Nobody has posted a review yet
    Rate / write a comment
  • Ask Expert: +44 (020) 3290 1199
    Sales representative and Consultant
    Casper Antechi

    Helpdesk

    +44 (020) 3290 1199

DS1 Docking station for wireless cameras charging

  • Automatically charging
  • Auto-Upload/Download
  • Password protection
  • Upload data by FTP to servers
  • Hierarchical managment

AvailableInStock

59052065

  • Print

More info

­Docking station DS1 for wireless cameras charging

DS1 is a professional docking station dedicated to wireless cameras. This is a highly advanced wireless camera management system. The device is able to charge 19 cameras simultaneously. 19'' LCD screen provides a great view and control of the ongoing processes.

The management software helps to efficiently collect the evidence. Moreover, the docking station DS1 protects the collected material. The cameras can be configured while being in the docking station. The system provides flexibility of operation and many customization options according to the user's needs.

Standard features of the DS1 docking station:

  • Docking station
  • All-in-one, comprehensive data management and storage server
  • Easy to use and maintain
  • Securely manages all video, photo and audio files from body cameras locally from the built-in 19" LCD touch screen
  • Complete health system monitoring
  • Fully charges body cameras in 6 hours, while simultaneously downloading video evidence from up to 20 cameras
  • Automatically clears docked body cameras' storage to prepare for next use
  • User management and permissions for added security
  • Evidence Management Software
  • User permissions and group access
  • Chain of custody tracking
  • Accidental deletion prevention
  • Customizable, detailed overview and reporting
  • Advanced search and review options for video, photo and audio
  • Case evidence management by authorized users from workstations through secure web logins
  • Open platform technology allows certain software customization based on agency's needs
­Specification of docking station DS1 for wireless cameras charging
Monitor19" LCD touch screen
Display resolution1280 × 1024
Internal storage60TB
External storage support (optional)NAS, SAN, DAS, SAS
RAID (optional)5
Charging capabilityup to 20 body worn cameras
Automatic data downloadsyes
Audio outputyes
External USB supportyes
External DVD supportyes
Disk usage statusyes
Evidence management softwareyes
Operating systemMicrosoft® Windows® 7 32-bit
ProcessorIntel® i3
ChipsetIntel® C602
MemoryDDR3 1600 MHz
RAM8 GB
DatabaseMicrosoft SQL
Operating systemSSD 60GB 2.5" SSD separate from integral storage
Networking connector typeRJ45
Interface100/1000 Mbps
NetworkGigabit
Network standardsIEEE802.3, IEEE802.3u, IEEE802.3x
Electrical Power Input110-240V AC
Max current10A
Power consumption650W typical 1000W max
Dimensions1,45 × 0,5 × 0,45m
Weight80kg
Inbox
  • Docking station DS1 for wireless cameras charging
  • User manual

Specification

­Specification of docking station DS1 for wireless cameras charging
Monitor19" LCD touch screen
Display resolution1280 × 1024
Internal storage60TB
External storage support (optional)NAS, SAN, DAS, SAS
RAID (optional)5
Charging capabilityup to 20 body worn cameras
Automatic data downloadsyes
Audio outputyes
External USB supportyes
External DVD supportyes
Disk usage statusyes
Evidence management softwareyes
Operating systemMicrosoft® Windows® 7 32-bit
ProcessorIntel® i3
ChipsetIntel® C602
MemoryDDR3 1600 MHz
RAM8 GB
DatabaseMicrosoft SQL
Operating systemSSD 60GB 2.5" SSD separate from integral storage
Networking connector typeRJ45
Interface100/1000 Mbps
NetworkGigabit
Network standardsIEEE802.3, IEEE802.3u, IEEE802.3x
Electrical Power Input110-240V AC
Max current10A
Power consumption650W typical 1000W max
Dimensions1,45 × 0,5 × 0,45m
Weight80kg

Inbox

  • Docking station DS1 for wireless cameras charging
  • User manual
