Flir thermal camera T530/540 with a laser range finder and revolving lens

  • Laser rangefinder
  • Radiometric video recordings
  • Edge outline - MSX
  • LCD touchscreen
  • Operation time of the Flir thermal camera up to 4 h

Available

Options:

Add to cart

  • Print

More info

T530/540 Flir thermal camera with a laser range finder and revolving lens

New series of professional thermal imaging cameras FLIR T530/540 which enable the user to find and solve the problems of thermal bridges and various faults. FLIR T530 / T540 cameras with their 180° rotating lens and bright 4” LCD screen help specialists in diagnosing difficult to reach elements in all types of environment.

T530/540 is a series of professional Flir thermal cameras with characteristic rotating arm enabling you to adjust the camera to highly difficult conditions in field. Now the operator will be able, without greater efforts, to examine surfaces or objects located just over his head. The Flir thermal camera features a number of functions that facilitate work and the removable lens increase possibilities of the device making the examination quick and precise.

  • Resolution

    Resolution of the Flir thermal camera

    Thermal imaging camera records infrared images in 320×240 resolution for the model T530 and 464×348 resolution for the model T540. The device produces clear and sharp image.

  • Moving lens

    Moving lens

    FLIR thermal camera T530/540 has been equipped with a rotating arm with a lens. This significantly facilitates 180° image controlling especially in difficult places.

  • Laser pointer

    Laser pointer

    The Flir thermal camera has a laser pointer that is located under the lens and can be used is different ways:

    • pointer - enables targeting a look at an object,
    • rangefinder - measuring the distance by sending and receiving the signal,
    • determining abnormalities on the given surface,
    • autofocus - enables automatic sharpening of the image.
  • MSX function

    MSX function

    MSX is the technology protected by the manufacturer’s patent. It enables outlining of edges on the thermal image. This function provides clearer image.

  • Local measuring parameters

    Local measuring parameters

    Using this function you can enter your individual parameters for each measured point, which enables precise specification of temperature differences of various objects.

  • Additional optics

    Additional optics

    You can change the lens to any of the 4 dedicated glasses (telephoto lens 14°x10°, versatile lens 24°x18°, wide angle lens 42°x32° and macro) and adjust your camera to the examined object or place.

  • LCD touchscreen

    LCD touchscreen

    The Flir thermal camera has been equipped with the LCD touchscreen which significantly facilitates work with the thermal imaging camera. There are also two buttons just above the screen to which you can assign the most frequently chosen functions of the camera.

  • Laser rangefinder

    Laser rangefinder

    The laser point enables quick determination of the distance from the examined object as well as precise designation of the area.

  • Radiometric video recording

    Radiometric video recording

    This function enables saving the image in .csq format, which allows for easy review of the recorded footage frame by frame.

  • Interface

    Interface

    The operator can send the collected footage to external devices via Wi-Fi or Bluetooth connection or directly connecting to the USB port.

  • Power supply and operation time

    Power supply and operation time

    The Flir thermal camera can be powered by constant power supply from the network or by lithium-ion rechargeable battery. Operating time of the thermal imaging camera is maximum 4 hours.

  • Comments

    Comments

    Functionality of the FLIR T530/540 thermal imaging camera enables you to comment on the recorded image using the voice or text notes that can be entered directly in the camera or created on an external device and then copied to the memory of the camera.

Product presentation

Manufacturer

FLIR Systems, Inc.

FLIR Systems, Inc. Is a brand which has been present on the market since 1978. It is considered a world leader in designing, producing and selling thermovision devices of wide scope of use. The constant development of the company and widening the scope of its projects resulted in...

Specification

­Specification of professional Flir thermal camera T530/540
 T530T540
unfiltered microbial detector matrix (FPA) 17 µm
320 × 240 (76,800 px)464 × 348 (161,472 px)
307,200 px645,888 px
1-4×1-6×
  • 42° - 0,15 m
  • 24° - 0,15 m
  • 14° - 1,0 m
24° / 103 µm24° / 71 µm
  • f/1,1 (42°)
  • f/1,3 (24°)
  • f/1,5 (14°)
7,5 - 14,0 µm
30 Hz
  • automatically using a laser
  • manual
+/- 2% or 2ºC
–15°C to +50°C
–40°C to +70°C
  • touchscreen
  • LCD 4"
  • 640×480
  • iron
  • gray
  • rainbow
  • arctic
  • lava
  • rainbow HC
  • infrared
  • visual
  • MSX@
  • image in image - movement resistant
yes
marking pictures
yes
memory cards up to 64 GB
jpeg
yes
  • H.264 or MPEG-4 with Wi-Fi
  • MJPEG or UVC or Wi-Fi
  • USB 2,0
  • Bluetooth
  • Wi-Fi
Li-Ion rechargeable battery
up to 4 h
  • 25 g / IEC 60068-2-27
  • 2 g / IEC 60068-2-6 / IP 54
  • EN/UL/CSA/PSE 60950-1
140 × 201 × 84 mm
1,3 kg

Inbox

  • T530/540 FLIR thermal camera
  • 2× rechargeable battery
  • Charger
  • Belt
  • Transport case
  • Lens cap
  • Wires
  • 8 GB memory card
  • User manual
