GPS tracking set - GPS GL300HM kit - discreet vehicle monitoring, up to 95 days operation

Reviews :

Brand:

Queclink

Reference:

69050905

Strong neodymium magnets
Discreet GPS tracking
Operation time up to 95 days
Waterproof design
GLONASS and GPS navigation technologies

GPS tracking set - GPS GL300HM kit - discreet vehicle monitoring, up to 95 days operation

304,42 $

Availability: Available

Delivery from Check the shipping costs

Place an order within And we will send your order today 12h 22m 54s

Do you need advice? Write to us

You dont know if you chose right? Leave your phone number and we will call you back

Description

GPS GL300HM kit - discreet route monitoring

The GL300HM kit consists of the GL300W GPS locator and a very strong magnetic mount, which allows the locator to be discreetly attached to, for example, the undercarriage of a car.

Working time

Up to 95 days
Data archiving

Online server
GPS module

GPS

GLONASS
Mounting

Neodymium magnet

The GL300 GPS locator is a compact, waterproof GPS transmitter. Its undoubted advantage is access to stored data, via internet-enabled mobile devices. The device is equipped with a sensitive U-blox M8 module, which provides transmitter location with ≤2 m accuracy. The magnetic mount has two very strong neodymium magnets, which allow the locator to be mounted, for example, in the chassis of a car.

GPS monitoring platform - price list for services
Price list for services and access to the professional GPS Trace location platform

Equipment in the GPS GL300HM kit

GL300W Server locator with GPS transmitter

The GPS GL300W Server is an extremely sensitive GPS transmitter with remote access to the server, via internet-enabled mobile devices.
GL200HM - magnetic holder for GPS locators

Two very strong neodymium magnets guarantee that the magnetic holder is permanently attached, for example, under the car.

Demonstration account for the GPS platform

By clicking on the link below, you can familiarise yourself with how the website for online access to the GPS locator data works. The login data are:

login: demospy
password: demospy

Server login panel

IMPORTANT!
Typical values for operating time and location accuracy are used in the specifications. Independently of us, these may change depending on the strength of the GPS signal.
The first year of use of the user platform is free of charge. Each subsequent 12 months are charged at an annual rate of GBP 59 (gross).

Specification

GL300HM kit specification
GL300W GPS locator specification
¹ full sky visibility
GPS chipset	U-blox M8 72 channels
GPS antenna	Integrated GPS / GLONASS Integrated GSM
Sensitivity	Typical: - 147 dBm Hot Start: - 155 dBm Location: - 162 dBm
Accuracy	Typical: <5m SBAS support: <2m
Start-up time¹	Cold Start: 60s (average) Warm Start: 30s Hot Start: 1s
Four-band GSM module	850/ 900/ 1800/ 1900 MHz
Compatibility	Class 4 (2 W at 850 , 900 MHz) Class 1 (1 W at 1800 / 1900 MHz) Class 3 (24+1/-3dBm) for UMTS 850/1900/2100
Device class	GPRS Class B
Multi-channel transmission class	GPRS multislot class 12
RMS phase shift error	<5°
Maximum RF power	33 dBm +/-2 dBm
Input dynamic range	-15 up to -107 dBm
Receiver sensitivity	Class II RBER (-107 dBm)
Frequency stability	<2,5 ppm
Maximum frequency error	±0,1 ppm
Power supply	Li-Poly 1300mAh, 3.7V battery
Standby power consumption	<10 μA
Working time	Sleep mode: up to 120 days Reporting every 10 minutes: up to 22 days Reporting every 5 min: up to 20 days Reporting every 3 min: up to 17 days Reporting every 1 min: up to 14 days
LED indicators	Power status GPS/GLONASS GSM
Waterproof	IPX5 standard
Dimensions	78 × 40 × 228 mm
Weight	93 g

Magnetic grip
Material	Material BS
Magnets	Neodymium magnets
Waterproof	Splash-proof
Dimensions	72 × 45 × 35 mm
Weight	70 g

Brand

Queclink

Queclink is a leading provider of wireless devices and solutions. It brings together an experienced team of specialist developers. We offer turnkey products for vehicle localization, fleet management, tracking and tracing of shipments, securing employees and much more. The brand's main strengths are its skilled engineering team and extensive experience in designing devices based on 2G, 3G, GPS, Bluetooth, WiFi, RFID, NFC, among other technologies.
