Hand- held thermal camera Dräger UCF 9000 for emergency services and fire departments

  • Sensor 384x288
  • Thermal and real image recorder
  • Digital zoom 4×
  • 8 operation modes
  • Explosion protection

Availability: AvailableInStock


£7,340.65 tax excl. £9,029.00tax inc.

Add to cart

  • Print

More info

Thermal cameras

Precise temperature measurement

Mobile thermal camera Dräger UCF 9000 for emergency services and fire departments

Manual thermal camera Dräger UCF 9000 is designed to be used during search and rescue, firefighting, and operations with hazardous materials. 384×288 sensor guarantees perfect visibility. Thermal and real image recorder allows current record of observatio

Thermal camera UCF 9000 by Dräger is upgraded version of UCF 8000. There are following advantages of this improved model: more operation modes (9 against 3), additional digital zoom 4× and function to record and take photos in thermal and real mode. Thanks to this feature, the device is perfect for search and rescue, detection of hazardous leakage, firefighting and training documentation. The camera is equipped with unrefrigerated sensor of 384×288 resolution which provides with an excellent visibility in difficult conditions (thick smoke, fog, darkness) and high temperatures. Solid case protects the device from water, dust, damages and extreme temperatures.

The most important features of thermal camera Dräger UCF 9000

  • Clear thermal image

    Clear thermal imagey

    384×288 sensor generates crystal clear image regardless of visibility conditions and surrounding temperature. The extended dynamic range will make it easier to detect people and objects even near fire.

  • 8 operation modes

    8 operation modes

    The user may select between 8 image modes adapted to different types of actions both indoors and outdoors.

    • regular view
    • a mode defined by the operator
    • people (search and rescue))
    • fire (firefighting))
    • thermal scan (detection of hot spots)
    • external (search and rescue in open area)
    • hazardous materials (leakage detection and level indication)
    • PLUS scan (detection of heat sources in real time)
  • Digital zoom 4x

    Digital zoom 4x

    The camera is equipped with digital zoom 4x enabling careful inspection of the area. It is addition to standard zoom x2.

  • Thermal and real image record

    Thermal and real image record

    The camera records thermal and real image in a form of videos and photos. If the memory card becomes full within approx. 2 hours, then the camera automatically overwrites the beginning of the video.

  • Laser pointer

    Laser pointery

    Integrated laser pointer is designed to show other team members sources or hear and all important objects.

  • Snapshot

    Snapshot

    Thanks to this function it is possible to stop an image on the screen to give it a closer look.

  • One-hand operation

    Easy, one-hand operation

    The device may be operated with a use of one hand only. Convenient function keys may be quickly selected with your index finger or thumb.

  • Indestructible construction

    Indestructible construction a

    Thermal camera UCF 9000 is fully protected from dust and water (according to IP67 class) and designed to be used in extreme temperatures: 20 minutes in 150°C and 10 minutes is 260°C .

  • Explosion protection

    Explosion protection

    Construction of the camera allows to use the device in potentially explosive environment including 1 Ex ATEX zone.

  • Duration up to 4 hours

    Duration up to 4 hours

    Powered by a lithium-ion battery, the device may be used to 4 hours in the temperature of 23°C.

Product video

Specification of a thermal camera Drager UCF-9000
Sensorunrefrigerated microbolometric sensor
Resolution384×288 px
Zoom
Sensitivity35 mK
Durationyto 4 h
Refresh50 Hz
Operation mode
  • standard
  • fire
  • people
  • thermal scan
  • open space
  • hazardous materials
  • PLUS scan
  • standard image – defined by the user
Protection classIP67
FOV
  • horizontal: 57°
  • vertical: 41°
  • diagonal: 74°
LCD screenLCD 3,5"
Operation temperatureyfrom -20°C to +50°C
Storage temperaturefrom -20°C to +65°C
Size125×280×110 mm
Weight1,4 kg
Inbox
  • Dräger UCF® 9000
  • Carrying case
  • Charger
  • Belt
  • User manual

Manufacturer

Drager

Dräger company has been on the market since 1889 under the motto "Technology for Life". From a small family business it has evolved into an international leader in medical and safety technology. The company is in constant development so that it is technologically one step ahead of ots...

Specification

Specification of a thermal camera Drager UCF-9000
Sensorunrefrigerated microbolometric sensor
Resolution384×288 px
Zoom
Sensitivity35 mK
Durationyto 4 h
Refresh50 Hz
Operation mode
  • standard
  • fire
  • people
  • thermal scan
  • open space
  • hazardous materials
  • PLUS scan
  • standard image – defined by the user
Protection classIP67
FOV
  • horizontal: 57°
  • vertical: 41°
  • diagonal: 74°
LCD screenLCD 3,5"
Operation temperatureyfrom -20°C to +50°C
Storage temperaturefrom -20°C to +65°C
Size125×280×110 mm
Weight1,4 kg

Inbox

  • Dräger UCF® 9000
  • Carrying case
  • Charger
  • Belt
  • User manual
