Handheld Raman spectrometer Anton Paar Cora 100 - detector of chemical substances

Cora 100 is a small and light handheld Raman Spectrometer. The device is perfectly adjusted to conduct quick tests and identify substances, such as: dangerous materials, drugs, explosive materials or chemical weapons and to verify the substances without having any chemistry knowledge. Intuitive interface and software as well as carefully worked on accessories allow for quick work and making key decisions that influence the area security.

•

  Simple use

•

  Safe for health

•

  Clear LCD screen

•

  Operation time up to 8 h

Measure and identify within a few seconds

The Handheld Raman Spectrometer Cora 100 has one task - to identify substances easily, fast and efficiently. Are you neither a qualified chemist nor an expert in the field of spectroscopy? It is not a problem: the portable spectrometer is equipped with an intuitive software and accessories as well as all the tools needed for the efficient identification of the substance. The handheld Raman specrometer can be used with gloves by using physical buttons, whereas the menu and the results are presented on the clear 3,5" screen. Cora 100 displays the result within seconds without the necessity to carry out complicated analyses, which shortens the time between the risk assessment and action.

It can be carried in a pocket and in a bag

Cora 100 is a practical, compact and handheld Raman Spectrometer of 16 cm x 10 cm x 3 cm size and 650 g weight. It meets the MIL-STD 810G military requirements and the European water and dust resistance requirements - IP67 protection class. It can work in a wide temperature range from -20 degrees to +40 degrees with high humidity. This manual spectrometer is adjusted to be used in different areas and weather conditions.

The whole chemistry knowledge you need

Cora 100, equipped with the Raman spectral spectrum base, is a comprehensive catalog of chemistry knowledge that enables to quickly identify dangerous materials, drugs, explosive materials, and chemical weapons. The result of a measurement is presented on the screen in an accessible way with the following information displayed: - the names of the substances in a sample, the degree of match to the pattern and classification of a given substance - whether it is dangerous, restricted or is a precursor of potentially dangerous materials. Additionally, the CAS numbers and security instructions can be displayed. The data bases can be adjusted to the individual needs - it is possible to create own bases and add new spectrum from the device level.

A managing software - in your language

"Cora 100 Connect" software enables to easily manage the device, data bases from the computer level in the local language version. "Cora 100 Connect" software has the embedded tools for creating, editing and managing the substances bases. It allows to save the measurements, transfer this data, create reports and manage the users within the whole organization. The software is available in the English language version by default. Optionally, the interfaces in Spanish, Mandarin, French and German are also available. Other language versions are available upon special request.

Use the best equipment - proper accessories in every situation

The Handheld Raman spectrometr Cora 100 is equipped with the adapter for spot measurements, angular adapter and a handle for test tubes. These accessories enable to take measurements through transparent plastic bags or glass without taking dangerous substances out of the packaging. The angular adapter allows to set the measurement position without touching the sample and performing manual measurements. A delayed measurement is helpful especially in the case of examining potentially explosive substances which can be set off after being lit with the laser beam.

Product video

Specification of the Handheld Raman spectrometer Cora 100
Laser	785 nm
Laser power	300 mW initial power, > 215 mW on sample
Bandwidth	400 cm-1 up to 2300 cm-1
Spectral resolution	max. 10 cm -1
Detector type	CCD liniar matrix
Display	TFT screen LED illumination
Software	Linux
Prezentacja danych	text, bandwidth
Interface	USB 2.0
Power supply of the handheld Raman spectrometer	built-in Li-Ion battery network 5 V DC/ 1 A USB
Operation time	up to 8 h/ 60 measurements
Operation temperature	-30 +50°С
Dimensions	158 × 100 × 29 mm
Weight	650 g

Inbox

• Handheld Raman spectrometer Cora 100
• Point measurement adapter
• 90° angle adapter with mounting tool
• Handle for samples
• Laser cover plugwith polystyrene sight for system testing
• Shoulder strap
• USB wire
• Tubes
• User manual
