Handheld thermal imaging monocular AGM Global Vision Protector for field observations

  • Rangefinder
  • Lesnses 25, 50, 75 mm
  • Protection class IP67
  • Operating time up to 5 hours
  • Optional Wi-Fi module

Availability: AvailableInStock

Options:


£2,439.02 tax excl. £2,999.99tax inc.

Add to cart

  • Print

More info

AGM Protector handheld thermal imaging monocular with rangefinder

The AGM Global Vision TC50 384 is a professional handheld thermal imager that makes night vision more effective than ever. Advanced components and solid construction create an equipment you can rely on in any situation.

  • Supported bands

    Refesh rate

    50 Hz

  • Operating time

    Operting time

    up to 5 h

  • WiFi module

    WiFi module

    optional

  • Waterproof

    Water resistance

    IP67

AGM Global Vision as been providing the market with advanced thermal imaging products for special tasks for several decades. AGM Protector handheld thermal imaging monocular is another modern product that meets the expectations of even the most demanding users. The equipment has been designed for effective observation in the field. Thanks to its robust construction and water resistance, the cap will work effectively even in harsh weather conditions and in the temperature range of -40°C to +70°C. Great observation potential is guaranteed by the high resolution of 384x288 at a refresh rate of 50 Hz. An important feature of handheld thermal imaging monocula is also a choice of up to 11 color palettes.

The most important features of AGM Global Vision Protector

  • 11 color palettes

    11 color palettes

    The ability to choose from 11 color palettes allows you to customize the image to your preference.

  • Three lens versionsu

    Three lens versions

    The thermal monocular is available with three lens options: 25, 50, and 75 mm, respectively for short, medium, and long-range observation.

  • Tactical observation

    4x digital zoom

    The 4x digital zoom allows for effective observation over long distances.

  • Rangefinder

    Rangefinder

    Modern rangefinder enables precise determination of distance to a target based on height estimation.

  • Rangefinder

    Optional Wi-Fi module and video recorder

    The Protector monocular can be equipped with an external Wi-Fi module which allows you to view images in real time via a mobile device, and a video recorder.

  • Remote control

    Remote control

    The wireless remote control function will come in handy during prolonged observation and tactical operations. The optional tripod mounting is an additional advantage.

Key features of the AGM handheld thermal imaging monocular:

  • optional video recording and Wi-Fi
  • 11 color palettes
  • rangefinder
  • remote control
  • integrated mounting rail MIL-STD-1913
  • digital zoom 1x, 2x, 4x
  • American production
­Specifications of AGM Protector handheld thermal imaging monocular
Sensor type
  • ULIS
  • uncooled
  • microbolometer
  • with vanadium oxide
Zoom1×, 2×, 4×
Lens
  • TM25 384: 25 mm; F/1.0
  • TM50 384: 50 mm; F/1.0
  • TM75 384: 75 mm; F/1.0
Resolution384×288
Refresh50 Hz
WiFi moduleyes
Digital zoom
  • TM25 384: 1,25×
  • TM50 384: 2,5×
  • TM75 384: 3,75×
Field of view7,5°×5,6°
Depth of focus10 m to ∞
Dioptric adjustmentfrom -5 to +5
Video recorderoptional
ScreenHD Display 1024×768
Protection classIP67
color palette settings11 color palettes
Pixel size17 μm
Operating timeto 5 hours
Power supply2 x CR123A 3V lithium batteries
Operating temperaturefrom -40°C to +70°C
Warranty3 years
Size
  • TM25 384: 195×70×58 mm
  • TM50 384: 225×70×64 mm
  • TM75 384: 250×93×93 mm
Weight
  • TM25 384: 0,44 kg
  • TM50 384: 0,55 kg
  • TM75 384: 0,69 kg
Inbox
  • Handheld night vision device AGM Protector with rangefinder
  • USB cable
  • Protective bag
  • User manual

Manufacturer

AGM Global Vision

AGM Global Vision - leading company in production of a wide variety of optical devices
