Industrial borescope Coantec C50 with illumination 4x magnification

Reviews :

Brand:

Coantec

Reference:

Probes of 3 diameters: 4,8/ 6/ 8 mm
Length of insert tubes from 1 up to 7 m
4-x magnification
Guiding joint movement 360°
Night illuminator

Industrial borescope Coantec C50 with illumination 4x magnification

6 707,95 $

Choose

Availability: Available

Delivery from Check the shipping costs

Do you need advice? Write to us

You dont know if you chose right? Leave your phone number and we will call you back

Description

Industrial borescope Coantec C50 with illumination 4x magnification and 360° probe

Coantec C50 is a great Industrial borescope for inspection of places with limited access. This model goes with probes of 3 diameters and various lengths of insert tubes. User friendly, multi-language menu, regulated illumination and great quality of picture – place the C50 model at the top of similar solutions.

Operation time

up to 3 h
Waterproof

IP 67
Display of the Industrial borescope

5" LCD
Intuitive menu

Display with a completely new, intelligent operating system

Industrial borescopes series C50 are equipped with a bright display LCD, which displays the picture also well in a daylight. New software is more user friendly and more practical.

Million pixels – excellent image processing technology

Miniature 720P HD image sensor makes the image more delicate and the colour more realistic. The image is uncompressed, the resolution is 1280×720, and every real detail is correctly reflected. Automatic exposure 0.1 seconds, automatic reduction of interference noise and high level of detail.

HDMI HD video output port

Equipped with HDMI video output interface, enables quick connection to a computer through a dedicated data cable.

Super light 100 000 lx

Illumination is 50 times higher than that of ordinary videoendoscopic cameras. It has 8 levels of brightness adjustment function. The light source can be adjusted accordingly on an ongoing basis.

Important!
It should be noted that operating time of the Industrial borescope depends to a large extent on intensity and time of using the LED light.

Simple navigation

Navigation is simple, placement and description of buttons is clear. Designed for persons without experience in handling inspection cameras.

Probe section diagram

The insertion tube is woven with tungsten alloy wire, which has a tighter braiding layer, which improves the wear resistance of the insertion tube by 20 times and effectively prolongs its service life. The C50 Series Industrial borescopes use sapphire protection lenses to effectively prevent the lens from being damaged.

Specification

Specification of the industrial borescope Coantec C50
Inspection wire	flexible φ 4,8/ 6/ 8 mm 10 m
Wire length	φ 4,8 mm - od 1 - 2 m φ 6/ 8 mm - od 1 - 7 m
Files format	jpeg avi
Depth of field	side: 3 - 30 mm front: 5 - 180 mm
Magnification of the industrial borescope	4-x
Display	5" LCD
Movable joint	range 360° bend angle max. 160°
Angle of view	70°/ 110°
Illuminator	20 - 100 lx adjustment - 8 levels
White balance	automatic
LED diodes	1×
Water-resistance	IP67
Data storage	memory cards up to 32 GB
Operation time of the industrial borescope	up to 3 h
Power supply	18550 mAh battery
Operation temperature	-10°C up to 50°C
Storage temperature	-20°C up to 60°C
Adissible humidity	up to 90%
Charging time	up to 3 h
Weight	1,3 kg

Brand

Coantec

Coantec is a company that is part of China's Shenzhen Coantec Automation Technology Co. specializing in the research, development and production of endoscopes, boroscopes and intelligent test robots. The company's products are used in the industrial, automotive and security sectors. The Coantec brand was established in 2012, focusing its business on the design and sale of videoscopes. Through the implementation of proprietary and innovative solutions, the company was the first to develop and release an HD industrial endoscope.

In box
