Industrial borescope Coantec C50 with illumination 4x magnification

  • Probes of 3 diameters: 4,8/ 6/ 8 mm
  • Length of insert tubes from 1 up to 7 m
  • 4-x magnification
  • Guiding joint movement 360°
  • Night illuminator

Availability: AvailableInStock

Options:


£5,739.00tax inc.

Add to cart

  • Print

More info

Industrial borescope Coantec C50 with illumination 4x magnification and 360° probe

Coantec C50 is a great Industrial borescope for inspection of places with limited access. This model goes with probes of 3 diameters and various lengths of insert tubes. User friendly, multi-language menu, regulated illumination and great quality of picture – place the C50 model at the top of similar solutions.

  • Work time

    Operation time

    up to 3 h

  • Transmission range

    Waterproof

    IP 67

  • Display

    Display of the Industrial borescope

    5" LCD

  • Camera wire

    Intuitive menu

Display with a completely new, intelligent operating system

Industrial borescopes series C50 are equipped with a bright display LCD, which displays the picture also well in a daylight. New software is more user friendly and more practical.

Million pixels – excellent image processing technology

Miniature 720P HD image sensor makes the image more delicate and the colour more realistic. The image is uncompressed, the resolution is 1280×720, and every real detail is correctly reflected. Automatic exposure 0.1 seconds, automatic reduction of interference noise and high level of detail.

HDMI HD video output port

Equipped with HDMI video output interface, enables quick connection to a computer through a dedicated data cable.

Super light 100 000 lx

Illumination is 50 times higher than that of ordinary videoendoscopic cameras. It has 8 levels of brightness adjustment function. The light source can be adjusted accordingly on an ongoing basis.
­

Important!
It should be noted that operating time of the Industrial borescope depends to a large extent on intensity and time of using the LED light.

Simple navigation

Navigation is simple, placement and description of buttons is clear. Designed for persons without experience in handling inspection cameras.

Probe section diagram

inspection camera Coantec M3

The insertion tube is woven with tungsten alloy wire, which has a tighter braiding layer, which improves the wear resistance of the insertion tube by 20 times and effectively prolongs its service life. The C50 Series Industrial borescopes use sapphire protection lenses to effectively prevent the lens from being damaged.

Specification of the industrial borescope Coantec C50
Inspection wire
  • flexible
  • φ 4,8/ 6/ 8 mm
  • 10 m
Wire length
  • φ 4,8 mm - od 1 - 2 m
  • φ 6/ 8 mm - od 1 - 7 m
Files format
  • jpeg
  • avi
Depth of field
  • side: 3 - 30 mm
  • front: 5 - 180 mm
Magnification of the industrial borescope4-x
Display5" LCD
Movable joint
  • range 360°
  • bend angle max. 160°
Angle of view70°/ 110°
Illuminator
  • 20 - 100 lx
  • adjustment - 8 levels
White balanceautomatic
LED diodes
Water-resistanceIP67
Data storagememory cards up to 32 GB
Operation time of the industrial borescopeup to 3 h
Power supply18550 mAh battery
Operation temperature-10°C up to 50°C
Storage temperature-20°C up to 60°C
Adissible humidityup to 90%
Charging timeup to 3 h
Weight1,3 kg
Inbox
  • Industrial borescope Coantec C50
  • Battery set
  • Memory card 8 GB
  • Charger
  • Card reader

Manufacturer

Coantec

The company focusing on development through the latest technologies, provides itself with a rapid promotion on the global market, gaining new representatives and recipients all over the world

Specification

Specification of the industrial borescope Coantec C50
Inspection wire
  • flexible
  • φ 4,8/ 6/ 8 mm
  • 10 m
Wire length
  • φ 4,8 mm - od 1 - 2 m
  • φ 6/ 8 mm - od 1 - 7 m
Files format
  • jpeg
  • avi
Depth of field
  • side: 3 - 30 mm
  • front: 5 - 180 mm
Magnification of the industrial borescope4-x
Display5" LCD
Movable joint
  • range 360°
  • bend angle max. 160°
Angle of view70°/ 110°
Illuminator
  • 20 - 100 lx
  • adjustment - 8 levels
White balanceautomatic
LED diodes
Water-resistanceIP67
Data storagememory cards up to 32 GB
Operation time of the industrial borescopeup to 3 h
Power supply18550 mAh battery
Operation temperature-10°C up to 50°C
Storage temperature-20°C up to 60°C
Adissible humidityup to 90%
Charging timeup to 3 h
Weight1,3 kg

Inbox

  • Industrial borescope Coantec C50
  • Battery set
  • Memory card 8 GB
  • Charger
  • Card reader
