Kowa camera SC200PK1C for 24/7 monitoring with higly sensitive matrix

  • 24-hour observation
  • Kowa camera has 1-10x digital zoom
  • Minimum lighting requirements 0.005 Lux
  • Bayer matrix and rolling shutter
  • IR Filter

AvailableInStock

  • Print

More info

SC200PK1C Kowa camera for 24/7 monitoring with higly sensitive matrix

Kowa camera for night observations SC200PK1C has been designed for day and night video monitoring and observation. Highly sensitive matrix provides clear colour image even after dark. It is the best solution for high-class monitoring systems.

  • Resolution

    Zoom

    ×10

  • Minimum Illumination

    Minimum Illumination of the Kowa camera

    0.005 lx

  • Image resolution

    Image resolution of the Kowa camera

    2,2 MPx

  • IR Filter

    IR Filter

This observation Kowa camera applies CMOS 2/3” converter which provides image in HD resolution (1080, 30fps). Highly sensitive matrix enables monitoring after dark. That is possible owing to the new type of sensor of the parameters similar to the most sensitive EMCCD matrix, the lighting requirements of which is 0.005 LUX. Moreover, the camera has an integrated sensitivity adjustment system that can work in automatic or manual mode and enables increase of sensitivity by 16 times and the WDR dynamics control algorithm. These features enable device operation in all conditions - it can work during the day as well as at night in very poor lighting. The day / night switch mode allows you to adjust the camera to the lighting conditions outdoors and enhance its effectiveness with the use of the IR lighting. Advanced noise eliminating algorithms guarantee clear image of good quality.

The Kowa camera is compatible with a wide range of CS-mounted objective lens Kowa brand also offers a wide selection of optics compatible with the camera, e.g. objective lens with the focal length from 25 to 1000 mm that are available in different functional versions with fixed or variable focal length, featuring auto-focus, manual or automatic aperture adjustment and zoom.

Kowa cameras and lens working together ensure clear and noise-free image with an ultimately minimized blur caused by the moving object even in very difficult lighting conditions, which is possible due to very low aperture values. With the 24-bit colour reproduction and high sensitivity of the camera you are able to obtain clear colour image that would reflect crucial details such as the face of a person in a car, behind the window or even green tree leaves behind the car, visible through two windows!

Presentation of Kowa camera potential

Specification of Kowa camera SC200PK1C for accurate 24/7 observations
Converter
SensorCMOS RGB with Bayer matrix and rolling shutter
Resolution of the Kowa camera
  • total number of pixels: 2270×1144, ~2,6,MP
  • number of active pixels: 1974×1100, ~2,2 MP
Pixel size5 μm
Matrix size2/3"
Scanningprogressive
Minimum illumination of the Kowa camera0,005 lx (F1.4, 30fps, 50IRE, +72dB, color)
Horizontal resolution900 TV lines
S/N ratio> 50dB (γ = 1, contour correction: OFF)
Lens mountingCS (maximum permissible intermediate ring 7 mm)
Shutter adjusting4-pin DC
Switching modes day/nightswitching IR filter (automatic / constantly / remote control)
Image functions
Electronic sensitivity adjustmentoff / auto (S/N, STD, MOVE) / manual; 1x, 2x, 4x, 8x, 16x
Gain control
  • automatic: AGC / HYPER-AGC
  • manual: 0-72dB
Electronic shutterOFF, 1/100, 1/125, 1/250, 1/500, 1/1000, 1/2000, 1/4000, 1/10000 s
Shadow correctionOFF, 1/100, 1/125, 1/250, 1/500, 1/1000, 1/2000, 1/4000, 1/10000 s
Gamma correction0,45 / 0,75 / 1
DNR (Dynamic noise regulation)OFF / LOW / HIGH
White balance of the Kowa cameraAuto Tracking White (ATW1 / ATW2) / Auto White Control (AWC) / manual
WDR dynamic modeOFF/ WDR / AUTO KNEE (automatic contrast curve adjustment) / AUTO BLACK STRETCH
Mist eliminating algorithmON / OFF
Color regulationRGB, CMYK
Other adjustable image parametersdetal / chroma / black level
Electronic zoom1-10×
Rotating imageHorizontally / vertically / horizontally and vertically
Privacy masks8 areas, mask white, gray and black
Test imagecolor bar, grayscale, crossed lines
General information
Video output
  • 1× HD-SDI (BNC)
  • 1× composite output VBS (BNC)
input synchronization signalVBS/3-value synchronization (BNC)
Serial portRS-485 (standard communication protocol)
Control inputturn on/off IR filter
Video output of the Kowa camera
  • HD-SDI – 1080i59.94 / 1080p30 / 1080p29.97 / 720p60 / 720p59.94 / 720p30 / 720p29.97 / 1080i50 / 1080p25 / 720p50 / 720p25
  • composite - NTSC, PAL down-conversion, Letterbox, Sidecut, squeeze
Power supply12 VDC +/- 10% (waving do 50mVp-p)
Power consumption7W
Permissible operating temperature range0°C - 50°C
Storage temperature of the Kowa camera-20°C - 60°C
Permissible humidity35% - 90%
Dimensions146×78×66 (witout lens)
Weight600g
StandardsCE (EN50130-4 / EN55022), RoHS
Inbox
  • Kowa camera SC200PK1C for accurate night observations
  • C/CS ring
  • Distance regulator from the matrix (flange focal distance)
  • User manual

Manufacturer

Kowa

Kowas is a well-known Japanse company, which specializes in high quality surveillance devices.
