On board camera HC-05A is a modern device designed for monitoring lorry semitrailers, national driving license exams conducted by the driving exam centres, as well as delivery vans during loading and unloading.
yes
yes
1080P
outdoor
in-car
On board Camera HC-05A has been designed to work in conjunction with a video-audio recorder with a GSM module which enables monitoring of what is happening to the car while a driver is away.
The on board camera generates images in resolution 1080P. It has 12 built-in diodes at the front to enlighten its vicinity. Sensitive matrix and low lightning requirements ensure sharp imaging also at night, in places with insufficient lightning such as any kinds of car parks or along the roads and etc. The housing made of hard metal protects the heart of the on board camera from adverse weather conditions and from the impact of branches of the trees passed along the road.
A great advantage of the camera HD HC-05A, apart from its perfect image quality, is that it makes it possible to observe the surrounding with the sound, so that the driver can control what is happening behind the lorry without leaving the cab. The on board camera can also be used for
If the sound recording is not required we recommend a similar Car camera HC-05,, which captures images without audio.
On boared camera HC-05A features excellent parameters e.g. HD resolution and water resistance which is why it’s the most often chosen device for monitoring delivery vans, lorries and fleet as well as for controlling the driving license exams.
Installation and service
We insure on-site installation of the monitoring sets for lorry semitrailers as well as the guarantee and post-guarantee service of the installed equipment. We also provide training in handling the car HD set.
In order to connect your camera to the recorder on a large distance you will need to use 6.2 or 9 meters long extension cords. The cameras are equipped with about 50 cm long cords as a standard.
Specification of On board camera HC-05A for day and night car monitoring with GSM module | |
---|---|
Matrix | OV4689 OmniVision, 4 Mpix |
Video codec: | H.264 |
Resolution of the on board camera | 1080P |
Angle of view | 120° |
Focal length | 2,8 mm |
Illumination | 0.1Lux @F1.8 |
Shutter | 1 / 10s ~ -1 / 100,000s |
Night mode | yes - 12 IR LEDs |
Sound | yes |
Waterproof | yes |
Power consumption of the on boared camera |
|
Power |
|
Operating temperature of the on board camera | -10°C ~ + 60°C |
Dimensions | 33,2 × 33,2 × 46,8 mm |
Inbox |
---|
Specification of On board camera HC-05A for day and night car monitoring with GSM module | |
---|---|
Matrix | OV4689 OmniVision, 4 Mpix |
Video codec: | H.264 |
Resolution of the on board camera | 1080P |
Angle of view | 120° |
Focal length | 2,8 mm |
Illumination | 0.1Lux @F1.8 |
Shutter | 1 / 10s ~ -1 / 100,000s |
Night mode | yes - 12 IR LEDs |
Sound | yes |
Waterproof | yes |
Power consumption of the on boared camera |
|
Power |
|
Operating temperature of the on board camera | -10°C ~ + 60°C |
Dimensions | 33,2 × 33,2 × 46,8 mm |
