Professional Listening Device Detector with LED screen - X Sweeper

  • Listening in on the intercepted transmissions
  • 5 different operation modes
  • Compatible with external devices
  • Professional counter-surveillance instrument
  • Professional Listening Device Detector with LED screen - X Sweeper

Ask for availability

59050036

Add email


£1,591.87 tax excl. £1,958.00tax inc.

Add to cart
  • Print

More info

Professional Listening Device Detector with LED screen - X Sweeper

X Sweeper is a professional bug detector designed for protection against analogue radio listening devices.

The professional detector operates in 30MHz to 3GHz range and scans the band in less than one second. All the detected signals are displayed as a spectrum on a clear LED display screen. It provides a wide spectrum of information about the transmissions in the vicinity and enables choosing a specific frequency for listening in through a built-in speaker. The detector also features a clock with auxiliary power.

Additionally, the device can be easily connected to a computer by an RS232 port (OptoSuite X software required), and supports the Optoelectronics Reaction Tune function.

X Sweeper is a handy device which allows to detect listening devices easily, and to protect oneself against surveillance of third parties.

  • Frequency range

    Frequency range of the professional listening device detector

    30MHz - 3GHz

  • Frequency range

    Clock

  • Frequency range

    Power_supply of the professional detector

    8 x AA battery

    Ni-Cd or Ni-MH batteries

    AC adapter

  • Display

    LCD display

Operation mode of X Sweeper

  • Sweep

    SWEEP

    Changing the middle frequency and bandwidth. Setting one of ten available sweeping ranges: 3GHz, 1 GHz, 300 MHz, 100 MHz.

  • Scan

    SCAN

    Scanning frequencies from a specific memory bank, previously saved in SWEEP or VFO modes.

  • Scan

    VFO

    Manual setting and saving of frequencies.

  • Memory

    MEMORY

    • 10 independent memory banks, 100 frequencies each,
    • saves up to 65000 events marked with date, time, geographical location (optionally)
    • signal interception automatically triggers recording with time, date, and relative signal power markings.
  • Log memory

    LOG MEMORY

    • a separate bank of 1919 frequencies capacity with date, time, signal power and geographical location (GPS connection required) markings
    • works parallel with SWEEP, SCAN and VFO modes
    • saving all the events, repeating frequencies included
Specification of the Professional Listening Device Detector with LED screen - X Sweeper
Frequency range of the listening device detector
  • 30 MHz-3 GHz
  • blocking GSM frequency – available only for users with permission
ModulationFM analog
Auto sweep time< 1s
Input impedance50 Ohm
BNC connectionyes
Sensitivity (typical)
  • 150 uV for 800 MHz
  • 500 uV for 1 GHz
  • 40 mV for 2.4-3 GHz
Input/Output
  • headphones 3.5 mm jack
  • Reaction Tune 2.5 mm jack
  • RS232
Power supply of the professional listening device detector
  • 8x AA battery
  • NiCad or NiMH accumulators
  • AC adapter - 9-12 V DC, 500 mA
Display128x64, LED backlight
Frequency display
  • 7 digits
  • 1 kHZ precision
Indicator of relative signal power50 segment – bar
Clockyes
Optionally
  • L1 GPS receiver (1575.42 MHz), C/A, 8 channels, constant following, 32 correlators
  • GPS antenna – 20 dB gain
Inbox
  • Professional Listening Device Detector with LED screen - X Sweeper
  • User manual

Manufacturer

Optoelectronics Security

Optoelectronics Security is a brand belonging to Optoelectronics, Inc. Company. For the last 40 years it has been a leading producer of unique and innovative anit-spy devices, such as frequency meters, camera and wiretappings detectors and localizers of hidden cell phones....
