Small voice recorder RF-Tech LR-64 with sound activation, recording schedule and great sound quality
Small voice recorder RF-Tech LR-64 with sound activation, recording schedule and great sound quality

  • Customer rating:
    Average: 0
    Nobody has posted a review yet
    Rate / write a comment
  • Ask Expert: +44 (020) 3290 1199
    Sales representative and Consultant
    John Paine

    Helpdesk

    +44 (020) 3290 1199

Small voice recorder RF-Tech LR-64 with sound activation, recording schedule and great sound quality

  • Knowles microphone range 12 m
  • Built-in memory 4 GB
  • Recording after motion detection
  • Converter resolution 12 bit / 8 bit
  • Work schedule

Availability: AvailableInStock

Options:


£348.78 tax excl. £429.00tax inc.

Add to cart

  • Print

More info

Small voice recorder RF-Tech LR-64 with sound activation, recording schedule and great sound quality

Professional RF-Tech LR-64 is a small voice recorder - just 21.2×15.3×3.3 mm, it guarantees excellent quality of the recorded sound, long operation time and advanced functions, in order to meet high requirements of professional users such as special services, the police or detectives, and at the same time to be easy to operate and user-friendly.

  • Schedule

    Schedule

    yes

  • Detection of sounds

    Sound detection

    yes

  • Range of the microphone

    Sound detection

    up to 12 m

  • Speaker

    Microphone

    Knowles

Very sensitive microphone guarantees high quality of the recorded sound and is able to record sounds of conversation at the distance of up to 12 m. The signal is sampled at a frequency of 5 to 48 kHz and processed by a microprocessor transducer system with a resolution of 12 bit. It is then saved in lossless PCM 16/8 bit format or with ADPCM 4 bit compression. Audio recordings are saved in the built-in 4 GB memory. A very important feature of the small voice recorder is the security of recordings - they can be encrypted using the 256-bit AES algorithm which makes them useless for unauthorized persons.

The small voice recorder offers various modes of operation

  • it can record in a continuous mode, with activation on sound (adjustment of trigger threshold and length of recording),
  • according to fixed schedules - weekly (choice of days of the week and hours of recording) or calendar (the user can specify the exact dates and times in which the device is to record).

The small voice recorder is powered with DC voltage in the range of 2 - 3.3 V. Thanks to this solution it can be easily adapt to the actual requirements, e.g. connected permanently, powered by a battery or rechargeable battery package, depending on the needs, it is possible to optimize the working time in relation to the size of the power source. Thanks to energy-saving technology, the device has a low power consumption - from 1 mA in standby mode to 18 mA when recording in the highest quality with 44 kHz sampling.

PC software was included for managing the small voice recorder settings and encrypted recordings. Parameter setting is carried out in a simple and intuitive way, all you need to do is to save the configuration file on the memory card, and after rebooting the recorder the settings will be read from the card.

Key features of the small voice recorder

  • miniature size - just 21.2×15.3×3.3 mm
  • very high sound quality - high-class microphone
  • energy-efficient technology and long operation time
  • universal external power supply DC 2 3.3 V
  • built-in 4 GB memory
  • recording in very high quality PCM 16/8 bit or with ADPCM 4 bit compression
  • 12 bit converter with 48 kHz sampling
  • data encryption using AES256
  • advanced sound activation of recording with adjustable parameters
  • recording time schedule (weekly and calendar recording schedules according to the set dates and times)
  • simple configuration thanks to the included PC software
Specification of the small voice recorder RF-Tech LR-64
Built-in memoryno
Recordings encryptionAES256
Micophone
  • Knowles 24
  • range 12
Memorybuilt-in 4 GB
Sound detectionyes
Recording scheduleyes
Compression algorithm16 bit PCM / 8 bit PCM / 4 bit ADPCM
Recording formatWAW
Sampling5 kHz - 48 kHz
InterfacemicroSB
Converter resolution12 bit / 8 bit
Automatic gain control (AGC)yes
Power supply of the small voice recorder
  • battery: CR 2025
  • DC 2 - 3,3 V
Electricity consumption
  • stand-by mode (recording schedule): 0,6 mA
  • stand-by mode (sound activation) 0,9 mA
  • recording with sampling 8 / 16 / 24 / 44 kHz: 3,3-4,2 / 5,0-7,1 / 6,4-9,6 / 11,7-18 mA
InterfacemicroUSB (configuarable through the file)
Supported systemsWindows ME, 2000, XP, Vista, 7, 8, 10
Dimensions of the small voice recorder21,2 × 15,3 × 3,3 mm (PCB with no external power supply)
Inbox
  • Small voice recorder RF-Tech LR-64
  • USB wire

Specification

Specification of the small voice recorder RF-Tech LR-64
Built-in memoryno
Recordings encryptionAES256
Micophone
  • Knowles 24
  • range 12
Memorybuilt-in 4 GB
Sound detectionyes
Recording scheduleyes
Compression algorithm16 bit PCM / 8 bit PCM / 4 bit ADPCM
Recording formatWAW
Sampling5 kHz - 48 kHz
InterfacemicroSB
Converter resolution12 bit / 8 bit
Automatic gain control (AGC)yes
Power supply of the small voice recorder
  • battery: CR 2025
  • DC 2 - 3,3 V
Electricity consumption
  • stand-by mode (recording schedule): 0,6 mA
  • stand-by mode (sound activation) 0,9 mA
  • recording with sampling 8 / 16 / 24 / 44 kHz: 3,3-4,2 / 5,0-7,1 / 6,4-9,6 / 11,7-18 mA
InterfacemicroUSB (configuarable through the file)
Supported systemsWindows ME, 2000, XP, Vista, 7, 8, 10
Dimensions of the small voice recorder21,2 × 15,3 × 3,3 mm (PCB with no external power supply)

Inbox

  • Small voice recorder RF-Tech LR-64
  • USB wire
