Tascam DR-70D recorder for professional audio recording

  • Tripod and camera mounting
  • Separate recording of two audio tracks
  • Checkpoint setting
  • Supports cards up to 128 GB
  • High quality audio

590538556


£284.54 tax excl. £349.99tax inc.

Add to cart

  • Print

More info

Tascam DR-70D audio recorder for professional audio recording

The Tascam DR-70D is a professional recorder for DSLR users to record high-quality audio with video. The ability to mount on the camera shoe allows you to create a compact set.

The Tascam DR-70D has two microphones that are ready for immediate use. In addition, it has four XLR/TRS jacks, which, when used with professional microphones, produce sound of incredible quality. In addition, it is possible to output the audio signal directly from the camera and monitor it with the recorder.

Strengths of the Tascam DR-70D audio recorder

  • Miniature sensitive microphone

    TWO BUILT-IN MICROPHONES

    Two omni-directional microphones make it easy to record natural sound. Using shotgun microphones, you can record, for example, the conversation of the people being filmed along with ambient noises.

  • 4 XLR/TRS combo jacks to expand configuration options

    4 COMBO XLR/TRS JACKS TO EXPAND CONFIGURATION POSSIBILITIES

    Four-channel recording gives you the ability to use two shotgun microphones and built-in microphones simultaneously, allowing you to record the conversation of two people on separate tracks.

  • High sound quality

    HIGH SOUND QUALITY - HDDA MICROPHONE PREAMPLIFIER

    The Tascam DR-70D features HDD preamplifiers. The operational amplifier is a NE5532 chip, which guarantees great audio recording quality. Thanks to the stealth architecture of this rejstrator, an equivalent noise figure of -120 dBu has been achieved. It is possible to record with a sampling rate of up to 96 kHz and 24-bit resolution.

  • Compact and robust design

    COMPACT AND ROBUST DESIGN

    When designing this recorder, the main consideration was its small size so that it would not interfere with the camera. In addition, the recorder has a thread for mounting on a tripod from the bottom and on top to the camera. It is also possible to mount the recorder in the flash sled.

  • Control tone generator

    CONTROL TONE GENERATOR

    The built-in generator allows recording control tones for aligning audio and video tracks. In addition, it is possible to add control signals at any time.

Specifications for the Tascam DR-70D digital recorder
General
PurposeDSLR filming
Memory cardsSDXC up to 128 GB
4 GB compression
  • WAV/BWF 16 bit/44.1 kHz (stereo) 6:44 h
  • WAV/BWF 24 bit/96 kHz (stereo) - 2:04 h
Power supply
  • 4 AA batteries
  • Tascam BP-6AA external power adapter (optional)
  • AC adapter (optional)
  • USB power supply
Operating time
  • 6 h - with XLR/TRS
  • 11 h - with MIC 3/4
Power consumption5 W
Compatible systemWindows XP, Windows Vista, Windows 7, Windows 8 (including 8.1), Mac OS X 10.2
Dimensions169 × 55 × 107 mm
Weight530 g without battery
Analog audio inputs and outputs
1/L, 2/R, 3/L, 4/RXLR-3-31, standard TRS 6.3 mm (can supply phantom power)
EXT IN 1/2stereo mini jack 3.5 mm (can supply plug-in power)
INstereo mini jack 3,5 mm
Phonesstereo mini jack 3,5 mm
OUT/LINE OUTstereo mini jack 3,5 mm
Other inputs and outputs
USB portMicro-B connector
FormatUSB 2.0 high speed
INstereo mini jack 3,5 mm
Phonesstereo mini jack 3,5 mm
OUT/LINE OUTstereo mini jack 3,5 mm
Audio parameters
Frequency response (LINE IN or MIC, IN or LINE, OUT, JEITA)
  • 20 Hz – 20 kHz +0,5/−2 dB (Fs 44,1/48 kHz)
  • 20 Hz – 20 kHz +0,5/−3 dB (Fs 96 kHz)
Distortion (LINE IN or MIC IN to LINE OUT, JEITA)0.02% or less (Fs 44.1/48/96 kHz)
Inbox
  • Tascam DR-70D audio recorder

Manufacturer

Tascam

Tascam - world leader in audio recording devices for musicians

Specification

Specifications for the Tascam DR-70D digital recorder
General
PurposeDSLR filming
Memory cardsSDXC up to 128 GB
4 GB compression
  • WAV/BWF 16 bit/44.1 kHz (stereo) 6:44 h
  • WAV/BWF 24 bit/96 kHz (stereo) - 2:04 h
Power supply
  • 4 AA batteries
  • Tascam BP-6AA external power adapter (optional)
  • AC adapter (optional)
  • USB power supply
Operating time
  • 6 h - with XLR/TRS
  • 11 h - with MIC 3/4
Power consumption5 W
Compatible systemWindows XP, Windows Vista, Windows 7, Windows 8 (including 8.1), Mac OS X 10.2
Dimensions169 × 55 × 107 mm
Weight530 g without battery
Analog audio inputs and outputs
1/L, 2/R, 3/L, 4/RXLR-3-31, standard TRS 6.3 mm (can supply phantom power)
EXT IN 1/2stereo mini jack 3.5 mm (can supply plug-in power)
INstereo mini jack 3,5 mm
Phonesstereo mini jack 3,5 mm
OUT/LINE OUTstereo mini jack 3,5 mm
Other inputs and outputs
USB portMicro-B connector
FormatUSB 2.0 high speed
INstereo mini jack 3,5 mm
Phonesstereo mini jack 3,5 mm
OUT/LINE OUTstereo mini jack 3,5 mm
Audio parameters
Frequency response (LINE IN or MIC, IN or LINE, OUT, JEITA)
  • 20 Hz – 20 kHz +0,5/−2 dB (Fs 44,1/48 kHz)
  • 20 Hz – 20 kHz +0,5/−3 dB (Fs 96 kHz)
Distortion (LINE IN or MIC IN to LINE OUT, JEITA)0.02% or less (Fs 44.1/48/96 kHz)

Inbox

  • Tascam DR-70D audio recorder
