Thermographic camera Flir E40/bx for precise measurements

Thermographic camera Flir E40/40bx is a professional device which allows for detecting threats, leaks or faults in installation.

Flir Exx series of thermal imaging cameras includes 6 devices E40/40bx, Thermal infrared camera E50/50bx and Thermal camera E60/60bx. E40/40bx version if the basic model in this series, with the lowest resolution IR 160 × 120 px and 2x digital zoom.

A very useful feature of the thermographic camera is possibility of WiFi connection with external devices such as tablets and laptops, which enables you to share images and have both close view or a distance view.

Key features of the thermographic camera Flir E40/E40bx

•

  Image refresh

  Frame rate of 60Hz ensures clear and full-motion image without ghosting effect.

•

  Accuracy

  Flir E40 thermographic camera accuracy is 2°C for the temperature range of -20°C do +650°C. Model E40bx features the same accuracy for the temperature range of –20°C up to +120°C.

•

  Additional optics

  The thermographic camera can be upgraded with additional optics e.g. wide-angle lens and telephoto lens to facilitate work in field. Additional lens are available upon individual order.

•

  Touch LCD screen

  The device has been equipped with a 3.5” LCD touchscreen. Additional advantage is auto-orientation function which automatically adjusts the image to the position of the camera.

•

  Laser Pointer and LED flashlight

  In the head of the Flir camera there is an LED diode located and a laser pointer which enables measuring out a specific point.

•

  PIP function (Picture In Picture)

  PIP function enables overlapping two images: thermal image over the standard image. This enables more precise location of the problem.

•

  File management

  Interface of the thermographic camera enables e.g. wireless transmission of reports via Bluetooth or with the use of mini USB, USB-A or video cable.

•

  Convenient power supply

  Device is powered by removable battery but it can also be powered by constant supply from electrical installation.

•

  Text and voice notes

  Operator can take text or voice notes of the maximum length of 60 seconds.

•

  Sturdy and reliable design

  The casing has been made of materials which aim to protect the crucial components of the thermographic camera against falling from 2 m height and shocks, as well as against varying weather conditions.
