USB inspection camera EN-07 is an excellent device which in cooperation with a smartphone enables the user to search slots in ceilings, walls and floors as well as to look in every place with limited access due to its small size.
OTTG supported devices
6 diodes
2 m
3,5 m
5 m
7 mm
Device model EN-07 can serve as a USB inspection camera for pipes, car wiring and several other places where there is a significantly limited access to. The EN-07 is compatible with smartphones and tablets that support USB OTG (On The Go). To be able to see the camera view you will need a free application available for devices with Android system.
The USB inspection camera for telephones has been equipped with 6 lighting diodes located around the miniature lens. Lighting right next to the lens enables to search the darkest corners. The device has a durable plastic sleeve casing with a diameter of not more than 7 mm. Flexible wire that connects the camera with the mobile device is available in 3 different lengths: 2 m, 3.5 m and 5 m. There is a controller (resembling a hand-free kit volume controller) in the wire to enable adjustment of light intensity.
The USB inspection camera for telephone is an excellent accessory that facilitates checking small slots and corners. The set is packed in an aluminium box that fits into a purse or a workwear pocket, so that you always have your camera close at hand.
| Specification of the USB inspection camera cable to the phone and tablet | |
|---|---|
| Converter | CMOS |
| Diameter of the USB inspection camera | 7 mm |
| Sensitivity | 0,3 Lux / 0 Lux (LED) |
| Camera angle | 60° |
| Resolution of the USB inspection camera | 480 TVL |
| Light intensity adjustment | yes |
| USB connector | microUSB |
| Lens illumination | 6 LEDs |
| Operation temperature of the USB inspection camera | -10 ~ +50°C |
| Cable lengths |
|
| Inbox |
|---|
| Specification of the USB inspection camera cable to the phone and tablet | |
|---|---|
| Converter | CMOS |
| Diameter of the USB inspection camera | 7 mm |
| Sensitivity | 0,3 Lux / 0 Lux (LED) |
| Camera angle | 60° |
| Resolution of the USB inspection camera | 480 TVL |
| Light intensity adjustment | yes |
| USB connector | microUSB |
| Lens illumination | 6 LEDs |
| Operation temperature of the USB inspection camera | -10 ~ +50°C |
| Cable lengths |
|
