DAHUA PFM800-E is a video converter used for video signal transmission via a ‘twisted-pair cable’ The set allows to adjust the impedance of 75 Ohm coaxial cable to the impedance of the ‘twisted pair’ cable, enabling correct video signal transmission at the distance of up to 400 m for 720P resolution and 250 m for 1080P resolution.
Connection schedule| Specification of the video converter for CCTV industrial cameras DAHUA PFM800-E | |
|---|---|
| 1The spression relates to 2 connected devices | |
| Standard |
|
| Type of the device | passive |
| Channel number | 1 |
| Video range |
|
| Supression 1 | 4.43 MHz @ 0.55 dB,11 MHz @ 0.84 dB,21 MHz @ 1.24 dB,38 MHz @ 2.85 dB,42 MHz @ 3.20 dB,67.5 MHz @ 2.87 dB |
| CMRR (db@ 5 MHz) | 60 db |
| Impedance of the coaxial connector | 75 Ω |
| Impedance of the coaxial connector | 100 Ω |
| Coaxial connector type | wtyk na przewodzie - BNC |
| Admissible humidity | < 95% |
| Typ złącza symetrycznego | spring clips |
| Operation temperature of the video converter | -10 °C - +55 °C |
| Dimensions | 49 × 20 × 20 mm |
| Weight | 190 g |
| Inbox |
|---|
