Wall scanner WallSpectra "Oracle" - professional system for seeing through a wall

WallSpectra "Oracle" is an advanced wall scanner that allows you to observe the area behind the wall. Scanning involves detection of micro-shocks, heartbeat and gestures of people behind the wall

WallSpectra "Oracle" is a small portable radar that has been designed for detecting people through behind the walls and non-metal obstacles. Its unique technology allows the radar to detect and locate people in motion and standing still. People locating can be displayed in 2D or 3D system. Thanks to its small size, light weight, long operation time and full mobility, WallSpectra "Oracle" wall scanner can be used in various situations and scenarios be the police, the army and special services. Highly advanced signal processing algorithms applied in the radar have been optimized so as to detect even the smallest movements of people or animals (e.g. breath) in order to enable locating them.

Application of the through-the-wall imaging radar

WallSpectra "Oracle" wall scanner is a solution dedicated to tactical application by the police, the army and other special forces. It allows you to assess the situation by providing information on the number and placement of people in the room before taking further action. It provides tactical advantage with the minimal risk taken by the officers, at the same time ensuring safety to the civilians. It can also be used for long-term monitoring of objects thanks to the ability of remote view on an external screen. The wall scanner also allows you to check vehicles, e.g. trucks for the presence of hidden people, without having to open the hideaway and unload them. The WallSpectra "Oracle" radar can operate as a portable control point if mounted on a tripod.

Technology

WallSpectra "Oracle" wall scanner applies the location technology based on wide-bandwidth UWB (UltraWide-Band) signals. It is distinguished by high resolution, interference resistance and no interference with other radio systems. The signal from the wall scanner is virtually imperceptible thanks to the use of SFCW (Step Frequency Continuous Wave). A great advantage of the device is easy penetration of signals generated by the radar through walls and other non-metallic surfaces. The image of people on the other side of the wall is generated on the basis of reflected signals, analysed and processed by the system.

Key features

• range up to 40 m
• lightweight design
• fully portable
• intuitive simple operation
• multilingual menu
• 2D and 3D imaging
• start-up time 20 s
• efficient power supply by the battery
• possibility to take 2-hours recording
• resistance class IP67
