X-Ray baggage scanner - EI-5030A
X-Ray baggage scanner - EI-5030A
  • Customer rating:
    Average: 0
    Nobody has posted a review yet
    Rate / write a comment
  • Ask Expert: +44 (020) 3290 1199
    Sales representative and Consultant
    Casper Antechi

    Helpdesk

    +44 (020) 3290 1199

X-Ray baggage scanner - EI-5030A

  • Accurate X-Ray baggage scanner - EI-5030A
  • Luggage and package scanning
  • Advanced image processing algorithms
  • Intuitive operation
  • Meets all safety norms

Availability: AvailableInStock

59051343


£20,999.99 tax excl. £20,999.99tax inc.

Add to cart

  • Print

More info

X-Ray baggage scanner - EI-5030A

EI-5310A model is a compact x-ray buggage scanner design from Eastimage brand.

Y-Ray buggage scanner is able to generate detailed clear image. The device meets all high radiation safety standards. Moreover, it is very user-friendly, thanks to comfortable easy-to-interpret preview and a variety of adjustable parameters.

Applications of the X-Ray buggage scanner
  • public spaces
  • meeting halls
  • official buildings
  • all places where safety is a concern

The most important features of the X-Ray Buggage Scanner EI-5030A

  • Clear image

    CLEAR IMAGE

    The detector generates clear image, making it easier to identify objects in the buggage.

  • Clear image

    FAST DATA PROCESSING

    The device's construction is based on top class electronic and analogue components, which guarantee reliability, stability and speed.

  • Intuitive operation

    INTUITIVE OPERATION of the X-Ray luggage scanner

    Intuitive comfortable and user-friendly panel enables the operator to adjust all parameters.

  • Intuitive operation

    Comfortable design

    The x-ray scanner was designed to facilitate simultaneous tunnel and display observation. It is rather small and very practical.

  • Adjustable settings

    ADJUSTABLE SETTINGS

    A multitude of functions accessible to an operator as well as advanced image processing algorithms enhance scanner efficiency and provide reliable image analysis.

  • Meets all standards

    MEETS ALL STANDARDS

    The device meets all norms dedicated to X-ray generators. Scanner's technical parameters meets (and in some cases exceeds) national norms GB15208-2005.

  • Odtwarzacz wideo

    Date & time display

  • Alarm functions

    Alarm functions of the x-ray baggage scanner

  • User management

    User management

  • Eagle-eye function

    Eagle-eye function

Standard features of the x-ray baggage scanner

    • Item counter
    • System running timer
    • X-ray emission meter
    • Running status indication
    • Self diagnosis
    • Emergency stop
    • Operator identification code
    • Automatic test on start
    • Image retrieval
    • Comfortable image browsing
    • Double-sided scanning
    • Image recognition algorithm
    • Network interface

Options

  • High density alarm
  • Threat Image Projection (TIP)
  • Operator Training Program (OTP)
  • One button shutdown
Specification of X-Ray baggage scanner - EI-5030A
Tunnel size505 × 305 mm
Conveyor speed0.2 m/s
Conveyor height730 mm
Maximum load160 kg (uniformly spaced)
System noise60dB (A)
Resolution of the x-ray luggage scanner
  • 40 AWG
  • tinning copper rod (0.0787 mm in diameter)
Material penetrationsteel ≥ 6 mm
Image resolution17"LCD 1280×1024
Spatial resolution
  • vertical resolution: ϕ1 mm
  • horizontal resolution: ϕ1 mm

X-ray generator

Anode voltage80 KV (adjustable)
Beam orientationupward
Cooling / duty cycleoil cooling/ 100%
X-ray detector
  • photoelectric
  • detector with diode matrix

Safety characteristics of X-ray generator

Dose per exam< 2μGy
Dispersed radiation
  • < 1μGy / h
  • measured from the distance of 5 cm from the radiation source
  • meets national and international safety standard
Safety of photographic materialsmeets ISO1600 standards (33DIN)
EU certificationCE
USA certificationFCC

Installation requirements

Dimensions of the x-ray baggage scanner1450 × 835 × 1200 mm
Weight375 kg
Operating temperature0°C ~ +45°C
Operating humidity20% ~ 95% (without condensation)
Storage temperature-40°C ~ +60°C
Storage humidity20% ~ 95% (without condensation)
Power supplyAC 220V (+10% ~ -15%), 50Hz
Power consumptioncirca 0.37kW
Inbox
  • X-Ray Buggage Scanner EI-5030A

Specification

Specification of X-Ray baggage scanner - EI-5030A
Tunnel size505 × 305 mm
Conveyor speed0.2 m/s
Conveyor height730 mm
Maximum load160 kg (uniformly spaced)
System noise60dB (A)
Resolution of the x-ray luggage scanner
  • 40 AWG
  • tinning copper rod (0.0787 mm in diameter)
Material penetrationsteel ≥ 6 mm
Image resolution17"LCD 1280×1024
Spatial resolution
  • vertical resolution: ϕ1 mm
  • horizontal resolution: ϕ1 mm

X-ray generator

Anode voltage80 KV (adjustable)
Beam orientationupward
Cooling / duty cycleoil cooling/ 100%
X-ray detector
  • photoelectric
  • detector with diode matrix

Safety characteristics of X-ray generator

Dose per exam< 2μGy
Dispersed radiation
  • < 1μGy / h
  • measured from the distance of 5 cm from the radiation source
  • meets national and international safety standard
Safety of photographic materialsmeets ISO1600 standards (33DIN)
EU certificationCE
USA certificationFCC

Installation requirements

Dimensions of the x-ray baggage scanner1450 × 835 × 1200 mm
Weight375 kg
Operating temperature0°C ~ +45°C
Operating humidity20% ~ 95% (without condensation)
Storage temperature-40°C ~ +60°C
Storage humidity20% ~ 95% (without condensation)
Power supplyAC 220V (+10% ~ -15%), 50Hz
Power consumptioncirca 0.37kW

Inbox

  • X-Ray Buggage Scanner EI-5030A
