X-RAY inspection system for luggage scanning - Autoclear 100100B

  • Conveyor pulling weight - 150kg
  • Tunnel size of the X-RAY inspection system for luggage scanning: 100 × 100 cm
  • Detection of suspicious objects
  • Intuitive operation
  • Conforms with safety regulations

AvailableInStock

69012305

  • Print

More info

X-RAY inspection system for luggage scanning - Autoclear 100100B

X-RAY inspection system for luggage scanning - Autoclear 100100B is a very effective construction created with fast and precise scanning of luggage, parcels and other large loads in mind.

The device is equipped with a conveyor belt with reversible direction, which makes it possible to easily load a scanned object. The generated image is very clear and can be adjusted to operator's preferences. The perfect device for detecting guns, knives, explosives or drugs.

Applications of Autoclear 100100B

  • airports and transshipment ports
  • courts
  • customs clearance
  • train and bus stations
  • official buildings
  • all types of public spaces
  • Clear image

    Clear image

    The X-RAY inspection system for luggage scanning - Autoclear 100100B generates clear image, making it easier to identify objects in the luggage.

  • Intuitive operation

    Intuitive operation

    Intuitive comfortable and user-friendly panel enables the operator to adjust all parameters.

  • Multi-energy screening

    Multi-energy screening

    Enables the analysis of densely-packed cases or large cargo.

  • Clear image

    Adjustable settings

    A multitude of functions accessible to an operator as well as various working modes:

    • organic/inorganic stripping
    • metal object recognition
    • object outlining
    • layer stripping
  • Clear image

    Different display modes of the X-RAY inspection system for luggage scanning

    • black and white image
    • colour image
    • negative/positive image
    • image magnification
    • image brightening
    • adjustable density alert

Optional features

  • Loading or exit roller beds
  • High-humidity kit
  • DVD drive
  • Dual conveyor motors
  • Auto material alert
  • Auto depth display
  • Image archiving
  • Threat image projection (TIP)
  • Built-in help
  • Level 1,2 and 3 networking
  • User management
  • Locking metal OCP cover
  • Dual or larger monitors
  • Locking monitor cover
  • Laser printer
  • Console desk
  • kV and mA meter
  • Uninterruptible power supply
  • X-ray sensor
  • Footpad
Specification of X-RAY inspection system for luggage scanning - Autoclear 100100B
Physical details
DisplayColour 17' monitor, 1280 x 1024 video card
Tunnel size1000 x 100 cm
Dimensions314.2 × 129.3 × 192.9 cm
Weight of the inspection system for luggage scanning
  • 126 kg – net weight
  • 998 kg – gross weight
Constructionunibody heavy gauge epoxy painted steel construction with stainless steel and aluminium trim; non-marking casters
Operating temperature of the Autoclear 100100B0°C ~ +40°C
Storage temperatureup to +65°C
Operating humidity20% ~ 95%
Storage humidity20% ~ 95%
Power consumption
  • < 0.7 kVA
  • < 7.5 amp 100, 110V AC±10%
  • < 3/75 amp 200, 220, 240, 250V, 50 or 60 Hz
X-ray generator
X-ray tube headself-contained
Anode voltage160 KV
Cooling / duty cycleoil cooling/ 100%
Beam orientationdiagonal (80° divergence)
Dose per exam0.1 mR
Inspection capabilities
Steel penetration28-29mm
Contrast sensitivitymore than 2 million colour tones
Resolution40 AWG (0.0799 mm)
Signal processing
  • 32-bit adaptive image processing
  • at least 1 GB of memory
  • 2.2 GHz or 2.4 GHz+ dual core processor
  • next generation video processing unit with 550MHz+
  • 512 Mb of video memory and 32 stream processing cores
Conveyor speed24cm/s (14.6m/minute)
Pulling weight150 kg
Film safetyguaranteed for high-speed film up to ISO 1600 (33 DIN)
Detectors
Detectors
  • L-shaped detector for 100% object screening
  • surface-mounted, multilayer, fully integrated, high frequency solid state detectors using high speed processors and Pentium 4 image processing
Standard features
SystemAutoSoft
Control panelwith touchpad navigation
Conveyor beltwith autoTracking® technology
Reversible conveyor directionyes
High/Low density recognition and layer strippingyes
Organic/inorganic strippingyes
Colour image
  • black and white
  • negative
Zoom
  • 128x
  • adjustable zoom
D-SCANyes
Dark and light enhanceyes
Density scanyes
Auto dense alertyes
Auto outlineyes
Auto sensingyes
Auto scaleyes
Auto calibartionyes
Z-SCANyes
Save screen to USByes
Item counteryes
Inbox

The standard equipment of the X-RAY inspection system for luggage scanning - Autoclear 100100B

  • Operational system AutoSoft
  • Full-sized remote control with touch navigation
  • Transmission zone with auto Tracking® technology
  • The function of changing the transmission zone
  • Detection of areas with high/low density
  • Detection of organic and nonorganic materials
  • Black and white or colourful image, negative
  • 128x Intelligent Zoom
  • Adjustable image zoom
  • D-SCAN
  • Black and white sharpening
  • Density detection
  • Density alarm
  • Edge marking
  • Automatic recognition
  • Automatic scaling
  • Autocalibration
  • Z-SCAN
  • Data storage on USB flash drives
  • Package counter
  • Intuitive menu with guidelines

Additional accessories

  • in/out roll feeder
  • Set for operation in an extreme humidity
  • DVD drive
  • Double engine of the transmission zone
  • Automatic alarm with danger detection function
  • Automatic depth display
  • Image archiving
  • TIP system
  • User help
  • Network connection of the 1,2 and 3 levels
  • User management
  • Metal cover for the remote control
  • Option of plugging in another monitor
  • Laser printer
  • Desk for the remote control
  • Lockup monitor cover
  • kV and mA meters
  • UPS Emergency feeder
  • RTG sensor
  • Tread

Manufacturer

AutoClear

The American company Autoclear is a brand with over 75 years of experience. X-ray scanning devices are different in size and arrangement of the conveyor belt and the scanning tunnel. The great advantage of the devices is the control panel, identical in every model. This solution...
