Thermal imager Pulsar Proton FXQ30 / XQ30 - AMOLED, waterproof, 16 Gb memory

  • Frost-resistant AMOLED display
  • Time to turn on the device, only 3 seconds
  • Smooth picture, even when moving
  • Long operating time on a single charge
  • Built-in modern PSP adapter

Options:


£1,552.84 tax excl. £1,909.99tax inc.

Add to cart

  • Print

More info

Pulsar Proton FXQ30 | XQ30 thermal imaging cap

Infinitely adjustable field of view, highest mechanical resistance, image recording function and built-in WiFi module - Pulsar Proton precision thermal imaging caps offer new possibilities in their field. They are the only ones on the market with regularly updated software to always stay one step ahead of other models.

Smooth image with detail

A sensitive sensor with a resolution of 384x288 pixels, together with an AMOLED display, provide clear, high-contrast images. Pulsar Proton thermal imaging caps easily visualize smaller objects, highlighting details. The observation comfort is also influenced by 8 color palettes, which allow you to customize imaging settings.

Versatile solution with high performance

The Pulsar Proton works with a variety of variable magnification optics. All you have to do is mount the cap on your scope with the modern PSP adapter, which fits scopes with a diameter of 50 mm and 56 mm (not included). What's more, it allows you to adjust the field of view and precisely position the cap in relation to the viewfinder point.

Improved operational stability

The FXQ30 and XQ30 models demonstrate operational readiness in just 3 seconds. They are made of magnesium alloy, which dissipates heat and thus improves image quality. It is durable - protecting the optics from shocks. Compared to other offerings, the Pulsar Proton is distinguished by the highest mechanical resistance to large calibers - 6000 J.

Trouble-free operation in harsh conditions

You do not have to worry about malfunctions - the manufacturer promises many years of operation even in extremely harsh conditions. After all, the caps can operate at temperatures from -25 to +50°C, and the display itself is additionally frostproof. IPX7 rating proves that the caps can be submerged in water up to 1 meter deep for 30 minutes.

Capture memories or evidence

With just one click, you can take a photo or start recording. The collected footage saves to the 16 GB internal memory. They can be shared via USB cable or mobile app.

Remote control

Proton thermal imaging headsets connect via WiFi to the free Stream Vision mobile app. From your phone, you'll watch video directly on the screen, download stored footage and change settings. You'll also update the software - Proton is the only one that gives its users access to the latest feature patches.

Large battery capacity

The "Display OFF" function turns the display on/off without terminating the device, thus saving battery power. The total operating time is about 6 hours. It can easily be extended by connecting an external power source (such as a powerbank).

The XQ30 cap included with the monocular

The Pulsar Proton XQ30 model comes with a 5x30B monocular, which turns the cap into a full-fledged observation thermal imager. It mounts to the back of the unit, without removing the adapter.

Product video

SPECIFICATIONS OF PULSAR PROTON CAPS
FQX30XQ30 (WITH 5X30 EYEPIECE)
Uncooled, 17 µm, 384×288
30 mm, F:1.2
900 m
12,4°×9,3°
-
-
AMOLED, 1024×768
1,5-4×
From the scope
6000 J
Yes
USB-C
Li-Ion Battery Pack APS5, USB-C 5V (external)
50 Hz
16 GB
.mp4 / .jpg
Up to 6 h
IPX7
from -25 °C to 50 °C
119 × 58 × 75 mm
380 g
Inbox
  • Pulsar Proton thermal imaging cap (FXQ30 or XQ30 depending on your choice)
  • Instruction manual
  • 1 × APS5 rechargeable battery
  • USB-C/230V charger
  • Cloth
  • Neck strap (only in proton XQ30)
  • Eyepiece cover
  • Cover
  • USB-C cable with USB adapter
  • Warranty card with hologram
  • Lens cap
  • Observation monocular 5x30 (only on proton XQ30)

Manufacturer

Specification

SPECIFICATIONS OF PULSAR PROTON CAPS
FQX30XQ30 (WITH 5X30 EYEPIECE)
Uncooled, 17 µm, 384×288
30 mm, F:1.2
900 m
12,4°×9,3°
-
-
AMOLED, 1024×768
1,5-4×
From the scope
6000 J
Yes
USB-C
Li-Ion Battery Pack APS5, USB-C 5V (external)
50 Hz
16 GB
.mp4 / .jpg
Up to 6 h
IPX7
from -25 °C to 50 °C
119 × 58 × 75 mm
380 g

Inbox

  • Pulsar Proton thermal imaging cap (FXQ30 or XQ30 depending on your choice)
  • Instruction manual
  • 1 × APS5 rechargeable battery
  • USB-C/230V charger
  • Cloth
  • Neck strap (only in proton XQ30)
  • Eyepiece cover
  • Cover
  • USB-C cable with USB adapter
  • Warranty card with hologram
  • Lens cap
  • Observation monocular 5x30 (only on proton XQ30)
