Endoscopic camera with 30 m cable and sturdy probe LevelFlex

LevelFlex by Laserliner is a professional tool which enables inspection of hard-to-reach places. A sturdy probe of the camera is protected by sapphire glass making it possible for the camera to access practically everywhere and its operating range is limited only by the 30 m long, 6 mm thick cable.

•

  Magnification

  digital 2x×

•

  Operation time of the endoscopic camera with 30 m cable and sturdy probe LevelFlex Laserliner

  min. 4 h

•

  Display of the endoscopic camera with 30 m cable and sturdy probe LevelFlex Laserliner

  5” LCD

•

  Power supply of the endoscopic camera with 30 m cable and sturdy probe LevelFlex Laserliner

  rechargeable battery

LevelFlex by Laserliner is a mast-have tool which allows you to penetrate pipes, sewer manhole, spaces between ceiling and floor and etc. The 31 mm probe of the camera has been made in layers with the use of materials that provide protection against dirt, dust and water according to the protection class IP68.30 m long cable is located on a reel that has a grip for a monitor so that to give the operator free hands to operate the cable where needed.

•

  Bright screen

  The inspection kit has been equipped with a bright 5” screen, of high resolution which provides detailed and clear image.

•

  Probe of the endoscopic camera with 30 m cable and sturdy probe LevelFlex Laserliner

  The 31mm probe and protection class IP68 enable operation of the device in humid environment. The lens made of szafirowango szkła is resistant to scratches, impact and other external factors.

•

  Data saving

  The endoscopic camera does not have a built-in disc, so the footage is stored on external SD cards.. Maximum supported capacity is 16 GB and it is able to store several hours of recorded footage. High quality of image enables detailed problem analysis. Video files are recorder with the speed of 30 fps with 640×480 resolution..

•

  Operation time and power supply of the endoscopic camera with 30 m cable and sturdy probe LevelFlex Laserliner

  LevelFlex Laserline endoscopic camera is powered by rechargeable battery which allows for up to 4 hours of continuous operation.. Battery consumption depends on the ambient temperature, intensiveness and of operation time of the illuminator.

•

  Image zoom

  2x digital zoom provides better view of the detected problem and faster diagnosis, as well as facilitates the way of action necessary to solve the problem.

•

  LED illuminator of the endoscopic camera with 30 m cable and sturdy probe LevelFlex Laserliner

  There are 10 diodes with brightness adjustment, located in the front part of the probe for better lightening of penetrated places.

•

  Retractable cable

  30 m long cable of the endoscopic camera is coiled on a reel to provide stability of the screen and work. Spring system secures against sudden retraction of the cable.

• Endoscopic camera PipeControl LevelFlex
• Memory card
• Power Supply
• Control cable
• Probe with cable 30 m
• Lens casings
• Screen
• Cable A/V
• User manual
