Waterproof outdoor camera with a GSM module TV-5220M and free configuration

  • Camouflaged outdoor camera
  • CMOS 12 Mpix matrix
  • Night vision IR diodes
  • Motion detection - 3 motion sensors
  • Sends image via MMS and e-mail





£339.00tax inc.

Add to cart
  • Print

More info

A waterproof outdoor camera with GSM module - TV-5220M

TV-5220M outdoor camera camera was designed to monitor any areas in any conditions, including extreme temperatures and high humidity. Thanks to many useful functions, the waterproof recorder can be operated remotely via GSM network.

Additionally, built-in GSM module immediately sends all taken photos to the pre-defined phone number or e-mail address. It is advisable to check the phone coverage prior to installing the wildlife camera. The outdoor camera is equipped with amplifying antennas, which guarantee strong signal even in remote areas.

  • Work time

    Work time

    3 - 6 months


  • Work time

    Power supply of the waterproof outdoor camera

    AA batteries

    mains power

  • Range sensor


    up to 25 m

  • usb

    USB port


Numerous built-in functions grant the TV-5220M outdoor camera a multitude of possible applications. The outdoor video recorder allows to observe both plants and animals living in a particular area without influencing the ecosystem. Moreover, waterproof camera can be used to monitor protected areas, breeding ponds, or large buildings, such as assembly halls, storehouses, or private houses.

  • For our clients we offer a free configuration service and full service and technical support during the life of the device. To get a fully configured phototrap enter in order comment password „CONFIGURATION” or contact with our Service:

    Detective Store - Service
    Unit 4e Enterprise Court
    South Yorkshire S63 5DB
    Phone: (44) 020 3290 1199
    E-mail: contact@detective-store.com

Main advantages of TV-5220M waterproof outdoor video recorder

  • Matrix


    Very sensitive CMOS sensor generates perfect video in 12 Mpix resolution.

  • infrared diodes


    In order to provide good-quality image during both day and night, the waterproof camera is equipped with built-in infrared diodes, which provide additional illumination in low light conditions.

  • motion sensors


    It is no longer necessary to record continuously thanks to three autonomous motion sensors. Two of them are located on the device's sides and inform about the approaching objects whereas the main sensor triggers recording whenever something crosses its field of view.

  • short time


    Less than 1s.

  • working modes


    • photo mode – takes 1-3 pictures when motion is detected
    • video mode – generates video recording 1-60s long when motion is detected
    • photo + video mode – takes 1-3 pictures and subsequently triggers video recording,
    • continuous photo mode – takes pictures at pre-set intervals (from 1 s to 24 h)
    • continuous video mode – records video file for a specified period of time.
  • Identification


    A unique name can be given to the outdoor camera in order to facilitate identification process.

  • Recording information


    User can stamp the recording with additional information, such as time, date, temperature or moon phase.

  • Clear display


    Easy-to-use colour LCD 2.36" display. Comfortable menu.

  • Password protection


    The outdoor video recorder can be protected from unauthorized access by PIN code (4 digits).

  • Adjustable resolution

    ADJUSTABLE RESOLUTION of the waterproof camera

    MMS image resolution - 640 × 480 or 320 × 240.

  • adjustable resolution


    Low battery alarm.

  • Supported gsm bands

    SUPPORTED GSM BANDS of the waterproof audio-video recorder

    850/900 and 1800/1900 MHz.

  • Included software


    Included CD contains all necessary configuration tools.

  • SIM


    The outdoor camera supports both rental and pre-paid phones.

  • Easy mounting


    Securing belts provide stability in any circumstances.

  • Waterproof casing


    Waterproof casing efficiently protects the outdoor camera against low temperatures and high humidity.

Materials to be downloaded

  • ­


    LTL photo trap update and configuration software.

Trail camera LTL TV-5220M


LTL Acorn

Little Acorn Outdoors Company was set up in 2009 in focusing on the sale of products for hunting and archery in the initial phase. Customer satisfaction, very good quality of products, reliability, and the growing interest of additional devices made Little Acorn gradually expanded the...


Specification of TV-5220M waterproof outdoor camera with a GSM module
MatrixCMOS 12 MPX
Angle of view52°
Focal lengthfrom 3 m to infinity
Exposure time of the outdoor cameraauto
White balanceauto
Image resolution
  • 12 MP 4000 × 3000 (about 2 MB)
  • 5 MP 2560 × 1920 (about 1 MB)
Image formatJPG
Video resolution
  • VGA 640 × 480 (about 60 MB / min)
  • QVGA 320 × 240 (about 30 MB / min)
Video formatAVI
Displaycolour LCD 2.36"
Motion detectionyes
Password protectionPIN (4 digits)
Built-in IR lamp24 diodes, 940 nm
Lamp rangeup to 13 m
Automatic lamp controlyes
Motion detection system
  • yes
  • 1x main sensor
  • 2x lateral sensors
Sensor range:up to 25 m
Sensor's angle of view35°
Adjustable sensor sensitivity3 levels
Programmable sensor stand-by time0 s - 60 min
Sensor activation time1 s
External memorySD cards up to 32 GB
Power supply of the waterproof outdoor camera
  • Camera module: 4 × AA batteries
  • GSM module: 4 × AA batteries
  • mains power
Operation time of a waterproof recorder
  • up to 3 months (4×AA batteries)
  • up to 6 months (8×AA batteries)
Low voltage alarm (SMS)yes
GSM module4 bands (850/900 and 1800/1900 MHz)
Interface of the outdoor camera
  • USB
  • TV output
Image sending
  • Via MMS - VGA 640 × 480 (preset phone number)
  • Via e-mail - preset e-mail address
  • Every minute image sending
SIM card support
  • pre-paid phones
  • rental phones
Working temperature- 30°C ~ +70°
Working humidity5 % ~ 95 %
Weight (without batteries)112 g
Dimensions of waterproof camera135 × 90 × 50 mm


  • Camera module
  • GSM module
  • Securing belt with clamp
  • Additional batteries holder case
  • USB cable
  • TV cable
  • CD with software
  • 24 month warranty
  • English user manual
