X-RAY baggage scanner - EI-V150150 / E-V150180

Reviews :

Reference:

59051347

Advanced digital technology
X-RAY baggage scanner - EI-V150150 / E-V150180 is designed for large luggage and packages scanning
Clear image, intuitive operation
Heavy-duty conveyor belt
X-RAY baggage scanner meets all safety regulations

X-RAY baggage scanner - EI-V150150 / E-V150180

Ask for price

Delivery from Check the shipping costs

Do you need advice? Write to us

You dont know if you chose right? Leave your phone number and we will call you back

Description

EI-V150150 / E-V150180 X-ray cargo inspection system

When searching for a dangerous object in an airport or a harbour, the biggest problem is usually the sheer size of cargo, pallets or packets. An efficient x-ray inspection system should be not only of great size but also have high material penetration coefficient and comply with strict environmental regulations. To meet these requirements Eastimage brand constructed the EI-V150150 / EIV180180 x-ray inspection system, which is equipped with a heavy-duty conveyor belt able to support up to 2000 kg and high quality x-ray generator providing clear x-ray image.

Applications of the X-RAY baggage scanner - EI-V150150 / E-V150180

airports
harbours
transshipment ports
official buildings
all types of public spaces

Clear image

The x-ray baggage scanner generates clear image, making it easier to identify dangerous objects even in a large luggage.
Fast data processing

The device's construction is based on top class electronic and analogue components, which guarantee reliability, stability and speed.
Intuitive operation

Intuitive comfortable and user-friendly panel enables the operator to adjust all parameters.
Durable design

Sturdy and durable casing and heavy-duty conveyor belt.
Adjustable settings

A multitude of functions accessible to an operator as well as advanced image processing algorithms enhance scanner efficiency and provide reliable image analysis.
X-RAY baggage scanner - EI-V150150 / E-V150180 meets all standards

The device meets all norms dedicated to X-ray generators. Scanner's technical parameters meets (and in some cases exceeds) national norms GB15208-2005.

Standard features

Date & time display
Item counter
System running timer
X-ray emission meter
Running status indication
User management
Self diagnosis
Alarm functions
Emergency stop
Operator identification code
Automatic test on start
Eagle-eye function
Image retrieval
Comfortable image browsing
Double-sided scanning
Image recognition algorithm
Network interface

Options

High density alarm
Threat Image Projection (TIP).
Operator Training Program (OTP).
One button shutdown

Specification

Specification of X-RAY baggage scanner - EI-V150150 / E-V150180
Characteristic
Tunnel size	1500×1505 mm 1550×1810 mm
Conveyor speed	0.2 m/s
Conveyor height	350 mm
Maximum load	2000 kg (uniformly spaced)
System noise	< 60 dB (A)
Resolution of X-RAY baggage scanner	36 AWG tinning copper rod (0.127 mm in diameter)
Material penetration	steel ≥ 40 mm
Spatial resolution	horizontal resolution: ϕ1.3 mm vertical resolution: ϕ1.3 mm
Image resolution	22"LCD 1920×1080

Image processing system
Display	colour black and white
Processing functions	F1/F2/F3 user-defined combinations, edge enhancement, partial image strengthening, negative, grey scale scanning
Image storage	100 000 pictures
Image resolution	1680×1050
Image processing and grey scale:	24-bit real-time processing /4096
Zoom	1x – 32x

X-ray generator
Anode voltage of EI-V150150 / E-V150180	160 KV/ 200 KV(adjustable)
Beam orientation	sideways
Cooling / duty cycle	oil cooling/ 100%
X-ray detector	photoelectric detector with diode matrix

Safety characteristics of X-ray generator
Dose per exam	< 2μGy
Dispersed radiation	< 1μGy/h measured from the distance of 5 cm from the radiation source meets national and international safety standard
Safety of photographic materials	meets ISO1600 standards (33DIN)
EU certification	CE
USA certification	FCC
Installation requirements
Dimensions	4350×2890×2070 mm 5150×2758×2500 mm
Dimensions	4350×2890×2070 mm 5150×2758×2500 mm
Weight of the X-RAY baggage scanner - EI-V150150 / E-V150180	3000kg 3300kg
Operating temperature	0°C ~ +45°C
Operating humidity	20% ~ 95% (without condensation)
Storage temperature	-40°C ~ +60°C
Storage humidity	20% ~ 95% (without condensation)
Power supply of EI-V150150 / E-V150180	AC 220V (+10% ~ -15%), 50Hz
Power consumption	circa 2.3kW
