Delta X 2000/6 anti surveillance system for detection of wiretaps, hidden cameras, as well as mobile phones

System Delta X 2000/6 anti surveillance system is a high-tech professional device intended for instant inspection of rooms to detect spy equipment.

The device comes with two antennas that cooperate to enable detection of all kinds of spy equipment such as wiretapping, cameras, audio-video recorders and even GPS locators. The antennas can be placed up to 15 meters from each other creating a search area between them. The closer Delta X system gets to the signal, the clearer indicators are.

Delta X 2000/6 is the 3rd version of modern countersurveillance systems of the Russian brand DigiScan Labs. The X 2000/6 version enables analysis of the band spectrum with the scanning speed of 2000-3000 MHz/sec and with 9 kHz intervals, which is quite innovative compared to the previous model X 100 4/12G. The applied technology allows to detect equipment that could contribute to the leakage of state-classified information or company business secrets. The digital receiver display complete information about all the radio transmissions present within the searched area.

The anti surveillance system of detecting wiretaps, micro cameras and other kinds of spy equipment together with the Delta X software create a highly reliable system used by Russian special operation forces for searching rooms for potential surveillance threat.

Key features of the anti surveillance system for detecting wiretapping Delta X 2000/6

•

  Instant spectrum scanning

  Increased sensitivity of the anti surveillance system Delta X 2000/6 enables instant scanning with the speed of 2000-3000 MHz and 9 kHz intervals. This way the duration of the signal emitted by spy equipment is 2-3 seconds, which is significantly shorter compared to the similar version X 100. The operator can very quickly inspect the room for detect wiretapping and other spy equipment.

•

  Signal detection

  System Delta X 2000/6 anti survaillance system is perfect at detecting both digital signals such as GSM, CDMA, 3G, 4G/ LTE, Bluetooth, Wi-Fi and etc., and analogue signals generated by e.g. voice recorders.

•

  System of antennas

  The use of two antennas enhances possibilities of the system and extends the range of detection. Placing the main antenna in one room and another antenna in another place max. 15 meter away enables searching for all signals present in the field between the two antennas.

•

  Scanning range of the anti surveillance system

  Detector of surveillance equipment uses the module that enables scanning a wide range of frequencies 4G: 40 kHz - 4400 MHz / 12G: 100 kHz - 12400 MHz.

•

  Different operation modes

  • Graphic presentation of results and alarms stored in the log (a table, graphs, spectrograms),
  • The main mode ‘RF scanning’ guarantees maximum response time and high sensitivity also when the operator or antennas move around,
  • the 24 h security - this mode rejects short signals and record only long-lasting signals. Reduced number of false alarms thanks to the use of two antennas,
  • detecting GPS locators, that has been left in vehicles, which also use GSM transmission
  • LF probe responsible for testing power lines, telephone lines, IR bands and bugging signals,
  • scanning of electromagnetic field enables detection of e.g. video cameras,
  • manual mode allows to carry out initial inspection of the radio waves environment,
  • analysis, demodulation and location of the detected signals
  • access to the general information about detected mobile networks and wireless transmissions in the area.
•

  Data recording

  The system functionality enables to record the data so that the operator can compare them later on and reject regularly coming signals.

•

  Graphical display of the results

  The Delta X software presents the results in graphical arrangements as:

  • broadband spectrogram
  • sonogram
  • graphs
•

  RF antennas and VLF probes

  The Delta X 2000/6 system comes with omnidirectional antennas, microwave antennas, IR probe, power line probe and low voltage telephone line probe.

Product video

• Software Delta X 1.0 - on a pendrive
• Spectrum analyzer SignslHound USB BB60C
• USB cable with chip
• DS-Line 2 Pro, VLF-convertor - the low-frequency converter
• MWA Microwave Antenna-6
• USB cable to the controller
• The connection cable DS-Libe2 Pro --antenna switch / Converter LF
• Carrying case
• 2 × omnidirectional antenna RF ODA-4
• Cable BNC-BNC
• Cable BNC-SMA
• Probe into AC power lines
• Infrared IR Probe for the Delta X 2000/6 anti surveillance system
• Telephone lines and low voltage probe
• Connection cable for probes

Manufacturer

DigiScan Labs

Digiscan Labs is a brand specializing in anit-spy systems , privacy protection and protecting key information . The experience of many specialists gained during Cold War was forged into modern systems protecting from any kind of wiretapping. They constantly introduce improvements,...
